CL1 audio mixer 56 channels 20
20000 Hz Black
Model CL1EAN 4957812518079
14 specifications
- Weight24 kg
- ColourBlack
- Channels quantity56 channels
- USB 2.0 ports quantity1
- Power consumption (typical)170 W
- Width648 mm
Overview
- Weight
- 24 kg
- Colour
- Black
- Channels quantity
- 56 channels
- USB 2.0 ports quantity
- 1
- Power consumption (typical)
- 170 W
- Width
- 648 mm
- Brand
- Yamaha
- Category
- Audio Mixer
- Model
- CL1
- Part number
- CL1
- EAN / UPC
- 4957812518079
- Also known as
- Yamaha CL1 audio mixer 56 channels 20 - 20000 Hz Black
Specifications
14 specifications in 5 groups
Audio
| Specification | Value |
|---|---|
| Channels quantity | 56 channels |
| Supported sample rates | 44.1,48 kHz |
| Frequency range | 20 - 20000 Hz |
| Signal delay (@48kHz) | 2.5 ms |
| Crosstalk (1kHz) | -100 dB |
| Gain adjustment range | -96 - 24 dB |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
Technical details
| Specification | Value |
|---|---|
| Product colour | Black |
| Video capability | No |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 170 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 648 mm |
| Depth | 667 mm |
| Height | 299 mm |
| Weight | 24 kg |
