IDATA SPDIF-10
Model IDATA SPDIF-10EAN 8059018369120
24 specifications
- Weight137 g
- ColourBlack
- Digital audio coaxial in1
- Sample rate96 kHz
- Power consumption (typical)1 W
- Width87 mm
Overview
- Weight
- 137 g
- Colour
- Black
- Digital audio coaxial in
- 1
- Sample rate
- 96 kHz
- Power consumption (typical)
- 1 W
- Width
- 87 mm
- Brand
- Techly
- Category
- Audio Converter
- Model
- IDATA SPDIF-10
- Part number
- IDATA SPDIF-10
- EAN / UPC
- 8059018369120
- Also known as
- Techly IDATA SPDIF-10 audio converter Black
Specifications
24 specifications in 7 groups
Inputs
| Specification | Value |
|---|---|
| Digital audio coaxial in | 1 |
| Audio (L/R) in | 1 |
| Digital audio optical in | 1 |
| USB 1.1 ports quantity | 0 |
Outputs
| Specification | Value |
|---|---|
| Digital audio coaxial out | 1 |
| Digital audio optical out | 1 |
| S/PDIF out port | Yes |
Technical details
| Specification | Value |
|---|---|
| Sample rate | 96 kHz |
| Supported sample rates | 48,88.2,64,32,96,44.1 kHz |
| Audio playback formats | LPCM |
| Compliance certificates | CE, RoHS |
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 1 W |
| Input voltage | 5 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 87 mm |
| Depth | 62 mm |
| Height | 25 mm |
| Weight | 137 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 90% |
Packaging data
| Specification | Value |
|---|---|
| Manual | Yes |
| Package type | Box |
