4K60 HDMI eARC Extractor
Model 38368EAN 4002888383684
36 specifications
- Weight83 g
- ColourBlack, Silver
- Digital audio coaxial in0
- HDCPYes
- Width65 mm
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 83 g
- Colour
- Black, Silver
- Digital audio coaxial in
- 0
- HDCP
- Yes
- Width
- 65 mm
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Lindy
- Category
- Audio Converter
- Model
- 38368
- Part number
- 38368
- EAN / UPC
- 4002888383684
- Also known as
- Lindy 4K60 HDMI eARC Extractor
Specifications
36 specifications in 7 groups
Inputs
| Specification | Value |
|---|---|
| Digital audio coaxial in | 0 |
| USB connector type | Micro-USB B |
| DC-in jack | Yes |
| Digital audio optical in | 0 |
| HDMI in | 1 |
| USB 1.1 ports quantity | 1 |
Outputs
| Specification | Value |
|---|---|
| Audio (L/R) out | 0 |
| Number of HDMI outputs | 2 |
Technical details
| Specification | Value |
|---|---|
| HDCP | Yes |
| HDCP version | 2.2 |
| Chipset | Sil9437CNUC |
| HDMI version | 2.0b |
| Bit rate | 24 bit |
| Supported sample rates | 192 kHz |
| Audio codecs | PCM 2.0, LPCM 5.1/ 7.1, Dolby Digital, Dolby Digital plus, Dolby TrueHD, Dolby Atmos, DTS 5.1, DTS ES 6.1, DTS HRA, DTS HD Master, DTS:X |
| Audio playback formats | LPCM, PCM |
| Housing material | Aluminium |
| Maximum resolution | 4096 x 2160 pixels |
| Product colour | Black, Silver |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 65 mm |
| Depth | 70 mm |
| Height | 27 mm |
| Weight | 83 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 20 - 90% |
Packaging content
| Specification | Value |
|---|---|
| Power cable length | 1 m |
Packaging data
| Specification | Value |
|---|---|
| Cables included | USB Type-A to Micro-USB Type-B |
| Manual | Yes |
| Quantity | 1 |
| Package width | 65 mm |
| Package depth | 70 mm |
| Package height | 27 mm |
| Package weight | 191.6 g |
| Package type | Box |
