Dahua Technology DHI-ASR2101A access control reader Basic access control reader

Dahua Technology

DHI-ASR2101A access control reader Basic access control reader

Model DHI-ASR2101AEAN 6939554950858

27 specifications

TypeBasic access control reader
Built-in displayNo
RS-485 ports1
Input voltage12 V
Depth15 mm
Operating relative humidity (H-H)5 - 95%

See all specifications

Overview

Type: Basic access control reader
Built-in display: No
RS-485 ports: 1
Input voltage: 12 V
Depth: 15 mm
Operating relative humidity (H-H): 5 - 95%

Brand: Dahua Technology
Category: Access Control Reader
Model: DHI-ASR2101A
Part number: DHI-ASR2101A
EAN / UPC: 6939554950858
Also known as: Dahua Technology DHI-ASR2101A access control reader Basic access control reader

Specifications

27 specifications in 8 groups

Technical details

Specification	Value
Type	Basic access control reader
Authentication type	Access chip/card, Password
Buzzer	Yes
Wiegand interface	Yes
Tamper protection	Yes
Access chip/card reader	Yes
Access code reader	Yes
Fingerprint reader	No
Keypad integrated	Yes
Keypad number of keys	12
International Protection (IP) code	IP66
Certification	CE; FCC

Display

Specification	Value
Built-in display	No

Camera

Specification	Value
Front camera	No

Ports & interfaces

Specification	Value
RS-485 ports	1

Power

Specification	Value
Input voltage	12 V
Input current	0.5 A
Power consumption (max)	1.7 W
Power consumption (typical)	0.9 W

Weight & dimensions

Specification	Value
Depth	15 mm
Height	123 mm
Width	86 mm

Packaging data

Specification	Value
Package depth	163 mm
Package height	71 mm
Package width	185 mm

Operational conditions

Specification	Value
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-30 - 70 °C
