DHI-ASI3223A access control reader Face recognition terminal Black
Model DHI-ASI3223AEAN 6923169713427
62 specifications
- Display10.9 cm (4.3")
- TypeFace recognition terminal
- Weight250 g
- ColourBlack
- Built-in displayYes
- Power consumption (typical)18 W
Overview
- Display
- 10.9 cm (4.3")
- Type
- Face recognition terminal
- Weight
- 250 g
- Colour
- Black
- Built-in display
- Yes
- Power consumption (typical)
- 18 W
- Brand
- Dahua Technology
- Category
- Access Control Reader
- Model
- DHI-ASI3223A
- Part number
- DHI-ASI3223A
- EAN / UPC
- 6923169713427
- Also known as
- Dahua Technology DHI-ASI3223A access control reader Face recognition terminal Black
Specifications
62 specifications in 8 groups
Technical details
| Specification | Value |
|---|---|
| Type | Face recognition terminal |
| Authentication type | Face recognition |
| Wiegand interface | Yes |
| Access chip/card reader | Yes |
| Access code reader | Yes |
| Active tampering alarm | Yes |
| Anti-passback | Yes |
| Audio prompt | Yes |
| Door contact input | 1 |
| Duress alarm | Yes |
| Exit button | Yes |
| Face capacity | 2000 |
| Face recognition accuracy | 99.9% |
| Face recognition distance | 0.3 - 1.5 m |
| Face recognition duration | 0.2 s |
| Fingerprint reader | No |
| Interoperability | ONVIF; CGI |
| Lock control | Yes |
| Open Supervised Device Protocol (OSDP) | Yes |
| Password capacity | 2000 |
| Real-time surveillance | Yes |
| Recommended usage | Indoor |
| Record capacity | 300000 |
| Remote verification | Yes |
| Software development kit (SDK) support | Yes |
| User capacity | 2000 user(s) |
| Voice prompts | Yes |
| Product colour | Black |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display diagonal | 10.9 cm (4.3") |
| Display type | LCD |
| Maximum resolution | 480 x 272 pixels |
| Screen shape | Flat |
| Touchscreen | Yes |
| Touchscreen technology | Capacitive |
Camera
| Specification | Value |
|---|---|
| Front camera | Yes |
| Front camera type | Dual camera |
| Sensor type | CMOS |
| Total megapixels | 2 MP |
| Maximum image resolution | 480 x 272 pixels |
| Infrared (IR) light | Yes |
| Wide Dynamic Range (WDR) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Supported network protocols | IPv4; RTSP; RTP; TCP; UDP; SIP; P2P |
| PC connected | No |
| RS-485 ports | 1 |
| USB port | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 18 W |
| DC current (max) | 1.5 A |
| DC voltage range | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 27.1 mm |
| Height | 115 mm |
| Weight | 250 g |
| Width | 118 mm |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 190 mm |
| Package height | 127 mm |
| Package weight | 400 g |
| Package width | 179 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | -10 - 40 °C |
