FSP Champ Rack 10KL
FSP

Champ Rack 10KL

Model Champ Rack 10KLPart no. PPF90A1201EAN 4713224524868

41 specifications
  • Noise50 dB
  • TypeRackmount/Tower
  • Weight18 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • USB portYes
See all specifications

Overview

Noise
50 dB
Type
Rackmount/Tower
Weight
18 kg
Colour
Black
UPS topology
Double-conversion (Online)
USB port
Yes
Brand
FSP
Model
Champ Rack 10KL
Part number
PPF90A1201
EAN / UPC
4713224524868
Also known as
FSP Champ Rack 10KL uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 9000 W

Specifications

41 specifications in 10 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity10 kVA
Output power9000 W
WaveformSine
Input operation voltage (min)110 V
Input operation voltage (max)300 V
Input frequency46/64 Hz
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Output frequency46/64 Hz
Output voltage regulation1%
Power factor0.9
Crest factor3:1
Emergency Power Off (EPO)Yes
Total Harmonic Distortion (THD) (linear load)3%
Total Harmonic Distortion (THD) (non-linear load)5%
Noise level50 dB

Ports & interfaces

USB portYes
USB 2.0 ports quantity1
USB port typeUSB Type-B
Serial interfaceYes
Serial interface typeRS-232
RS-232 ports1
Emergency Power Off (EPO) connectorYes

Battery

Number of batteries supported20

Design

Form factorRackmount/Tower
Product colourBlack
Control typeButtons
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 90%

Packaging content

Cables includedInput power cable, USB cable
ManualYes

Certificates

Compliance certificatesCE

Weight & dimensions

Width580 mm
Depth438 mm
Height133 mm
Weight18 kg

Logistics data

Harmonized System (HS) code85078000

Other features

Packaging contentUPS, user manual, software CD, USB cable, cable for battery pack
