Product comparison · 2 uninterruptible power supplies (upss)

FSP Champ Rack 10KL vs FSP Champ Tower 6KL

35specifications compared
6differ
29identical
14known for one product only

Key differences

Output power capacity
- Champ Rack 10KL:10 kVA
- Champ Tower 6KL:6 kVA
Output power
- Champ Rack 10KL:9000 W
- Champ Tower 6KL:5400 W
Power factor
- Champ Rack 10KL:0.9
- Champ Tower 6KL:0.99
Noise level
- Champ Rack 10KL:50 dB
- Champ Tower 6KL:55 dB
Form factor
- Champ Rack 10KL:Rackmount/Tower
- Champ Tower 6KL:Tower
Operating relative humidity (H-H)
- Champ Rack 10KL:20 - 90%
- Champ Tower 6KL:0 - 95%

Side by side

Differences highlightedShow differences only

Comparison of Champ Rack 10KL, Champ Tower 6KL
49 specifications	A FSP Champ Rack 10KL View product	B FSP Champ Tower 6KL View product
Features4 differ
UPS topology	Double-conversion (Online)	Double-conversion (Online)
Output power capacityDiffers	10 kVA	6 kVA
Output powerDiffers	9000 W	5400 W
Waveform	Sine	Sine
Input operation voltage (min)	110 V	110 V
Input operation voltage (max)	300 V	300 V
Input frequency	46/64 Hz	46/64 Hz
Output operation voltage (min)	208 V	208 V
Output operation voltage (max)	240 V	240 V
Output frequency	46/64 Hz	46/64 Hz
Output voltage regulation	1%	1%
Efficiency (Battery mode)Known for one	Unknown — not stated by the source	90%
Efficiency (Line Mode)Known for one	Unknown — not stated by the source	92%
Power factorDiffers	0.9	0.99
Crest factor	3:1	3:1
Emergency Power Off (EPO)	Yes	Yes
Total Harmonic Distortion (THD) (linear load)	3%	3%
Total Harmonic Distortion (THD) (non-linear load)	5%	5%
Noise levelDiffers	50 dB	55 dB
Ports & interfacesidentical
USB port	Yes	Yes
USB 2.0 ports quantity	1	1
USB port type	USB Type-B	USB Type-B
Serial interface	Yes	Yes
Serial interface type	RS-232	RS-232
RS-232 ports	1	1
Emergency Power Off (EPO) connector	Yes	Yes
Batteryidentical
Number of batteries supported	20	20
Typical backup time at full loadKnown for one	Unknown — not stated by the source	10 min
Design1 differ
Form factorDiffers	Rackmount/Tower	Tower
Product colour	Black	Black
Cooling typeKnown for one	Unknown — not stated by the source	Active
Built-in fanKnown for one	Unknown — not stated by the source	Yes
Control type	Buttons	Buttons
Display type	LCD	LCD
LED indicators	Yes	Yes
Operational conditions1 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)Differs	20 - 90%	0 - 95%
Operating altitudeKnown for one	Unknown — not stated by the source	0 - 1000 m
Certificatesidentical
Compliance certificates	CE	CE
Sustainabilityidentical
Sustainability complianceKnown for one	Unknown — not stated by the source	Yes
Packaging dataidentical
Resource CDKnown for one	Unknown — not stated by the source	Yes
Logistics dataidentical
Harmonized System (HS) code	85078000	85078000
Other featuresidentical
Packaging content	UPS, user manual, software CD, USB cable, cable for battery pack	UPS, user manual, software CD, USB cable, cable for battery pack
Packaging contentidentical
Cables includedKnown for one	Input power cable, USB cable	Unknown — not stated by the source
ManualKnown for one	Yes	Unknown — not stated by the source
Weight & dimensionsidentical
WidthKnown for one	580 mm	Unknown — not stated by the source
DepthKnown for one	438 mm	Unknown — not stated by the source
HeightKnown for one	133 mm	Unknown — not stated by the source
WeightKnown for one	18 kg	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
