Product comparison · 2 uninterruptible power supplies (upss)

FSP Champ Rack 10KL vs FSP Champ Rack 6KL

40specifications compared
6differ
34identical
1known for one product only

Key differences

Output power capacity
- Champ Rack 10KL:10 kVA
- Champ Rack 6KL:6 kVA
Output power
- Champ Rack 10KL:9000 W
- Champ Rack 6KL:5400 W
Operating relative humidity (H-H)
- Champ Rack 10KL:20 - 90%
- Champ Rack 6KL:0 - 95%
Width
- Champ Rack 10KL:580 mm
- Champ Rack 6KL:530 mm
Height
- Champ Rack 10KL:133 mm
- Champ Rack 6KL:88 mm
Weight
- Champ Rack 10KL:18 kg
- Champ Rack 6KL:15 kg

Side by side

Differences highlightedShow differences only

Comparison of Champ Rack 10KL, Champ Rack 6KL
41 specifications	A FSP Champ Rack 10KL View product	B FSP Champ Rack 6KL View product
Features2 differ
UPS topology	Double-conversion (Online)	Double-conversion (Online)
Output power capacityDiffers	10 kVA	6 kVA
Output powerDiffers	9000 W	5400 W
Waveform	Sine	Sine
Input operation voltage (min)	110 V	110 V
Input operation voltage (max)	300 V	300 V
Input frequency	46/64 Hz	46/64 Hz
Output operation voltage (min)	208 V	208 V
Output operation voltage (max)	240 V	240 V
Output frequency	46/64 Hz	46/64 Hz
Output voltage regulation	1%	1%
Power factor	0.9	0.9
Crest factor	3:1	3:1
Emergency Power Off (EPO)	Yes	Yes
Total Harmonic Distortion (THD) (linear load)	3%	3%
Total Harmonic Distortion (THD) (non-linear load)	5%	5%
Noise level	50 dB	50 dB
Ports & interfacesidentical
USB port	Yes	Yes
USB 2.0 ports quantity	1	1
USB port type	USB Type-B	USB Type-B
Serial interface	Yes	Yes
Serial interface type	RS-232	RS-232
RS-232 portsKnown for one	1	Unknown — not stated by the source
Emergency Power Off (EPO) connector	Yes	Yes
Batteryidentical
Number of batteries supported	20	20
Designidentical
Form factor	Rackmount/Tower	Rackmount/Tower
Product colour	Black	Black
Control type	Buttons	Buttons
Display type	LCD	LCD
LED indicators	Yes	Yes
Operational conditions1 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)Differs	20 - 90%	0 - 95%
Packaging contentidentical
Cables included	Input power cable, USB cable	Input power cable, USB cable
Manual	Yes	Yes
Certificatesidentical
Compliance certificates	CE	CE
Weight & dimensions3 differ
WidthDiffers	580 mm	530 mm
Depth	438 mm	438 mm
HeightDiffers	133 mm	88 mm
WeightDiffers	18 kg	15 kg
Logistics dataidentical
Harmonized System (HS) code	85078000	85078000
Other featuresidentical
Packaging content	UPS, user manual, software CD, USB cable, cable for battery pack	UPS, user manual, software CD, USB cable, cable for battery pack

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
