SIM-NT 2.7 GHz Windows Embedded Standard 2009 2.5 kg Black 235e
Model SIM-NTPart no. SBB-SMDFADEAN 8806071290386
30 specifications
- ProcessorAMD Athlon II X2
- Memory1 GB
- Storage40 GB
- OSWindows Embedded Standard 2009
- Weight2.5 kg
- ColourBlack
Overview
- Processor
- AMD Athlon II X2
- Memory
- 1 GB
- Storage
- 40 GB
- OS
- Windows Embedded Standard 2009
- Weight
- 2.5 kg
- Colour
- Black
- Brand
- Samsung
- Category
- Thin Client
- Model
- SIM-NT
- Part numbers
- SBB-SMDFAD, SBB-SVDSBD
- EAN / UPC
- 8806071290386, 8806071741222
- Also known as
- Samsung SIM-NT 2.7 GHz Windows Embedded Standard 2009 2.5 kg Black 235e
Specifications
30 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 2.7 GHz |
| Processor family | AMD Athlon II X2 |
| Processor model | 235e |
| Motherboard southbridge | AMD SB710 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 1 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 40 GB |
Audio
| Specification | Value |
|---|---|
| Audio system | Realtek ALC262 |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 4 |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Serial ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Display included | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Embedded Standard 2009 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 45 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 3.4 kg |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 310 x 282 x 52.2 mm |
| Graphics card | Radeon HD 3200 |
| Graphics card family | AMD |
| HDD interface | Serial ATA II |
| HDD size | 2.5" |
| Networking features | Gigabit Ethernet |
| Package dimensions (WxDxH) | 441 x 375 x 149 mm |
| Power requirements | 100-240V |
| Power supply type | AC |
