M715 Tiny
Model M715 TinyPart no. 10VL0006USEAN 192563936862
59 specifications
- ProcessorAMD PRO A10
- Memory8 GB
- Storage128 GB
- SpeedWi-Fi 5 (802.11ac)
- OSWindows 10 IoT Enterprise
- Weight1.32 kg
Overview
- Processor
- AMD PRO A10
- Memory
- 8 GB
- Storage
- 128 GB
- Speed
- Wi-Fi 5 (802.11ac)
- OS
- Windows 10 IoT Enterprise
- Weight
- 1.32 kg
- Brand
- Lenovo
- Category
- Thin Client
- Model
- M715 Tiny
- Part numbers
- 10VL0006US, 10VL000DUS, 10VL000YUS, 10VL000XUS, 10VL000FUS, 10VL000BUS +2 more
- EAN / UPC
- 192563936862, 192563938767, 193638968733, 193638968924 +4 more
- Also known as
- Lenovo M715 Tiny 2.8 GHz Windows 10 IoT Enterprise 1.32 kg Black A10-8770E
Specifications
59 specifications in 16 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 2.8 GHz |
| Processor manufacturer | AMD |
| Processor family | AMD PRO A10 |
| Processor model | A10-8770E |
| Processor cores | 4 |
| Processor boost frequency | 3.5 GHz |
| L2 cache | 2 MB |
| Motherboard chipset | AMD B300 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2666 MHz |
| Memory slots | 2x SO-DIMM |
| Memory layout (slots x size) | 1 x 8 GB |
| Maximum internal memory | 8 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 128 GB |
| Storage media | SSD |
| Storage drive interface | PCI Express |
| Card reader integrated | No |
| NVMe | Yes |
| SSD form factor | M.2 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | AMD Radeon R7 |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| Speaker power | 1.5 W |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Qualcomm |
| WLAN controller model | Qualcomm QCA6174A |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Combo headphone/mic port | Yes |
| DisplayPorts quantity | 3 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cable lock slot type | Kensington |
Display
| Specification | Value |
|---|---|
| Display included | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 IoT Enterprise |
| Operating system language | English |
| Trusted Platform Module (TPM) | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 65 W |
Certificates
| Specification | Value |
|---|---|
| Certification | MIL-STD-810G |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ErP |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 179 mm |
| Depth | 183 mm |
| Height | 37 mm |
| Weight | 1.32 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
| Keyboard included | Yes |
| Keyboard language | English |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
