Samsung PIM-B 1.7 GHz Windows Embedded Standard 7 1.2 kg Black A6-3430M
Model PIM-BPart no. SBB-PF28BP4EAN 8806086236300
34 specifications
- ProcessorAMD A6
- Memory4 GB
- Storage32 GB
- OSWindows Embedded Standard 7
- Weight1.2 kg
- ColourBlack
Overview
- Processor
- AMD A6
- Memory
- 4 GB
- Storage
- 32 GB
- OS
- Windows Embedded Standard 7
- Weight
- 1.2 kg
- Colour
- Black
- Brand
- Samsung
- Category
- Thin Client
- Model
- PIM-B
- Part numbers
- SBB-PF28BP4, SBB-PF32BV4, SBB-PE32BV4, SBB-PE64BP4
- EAN / UPC
- 8806086236300, 8806086236324, 8806086419017
- Also known as
- Samsung PIM-B 1.7 GHz Windows Embedded Standard 7 1.2 kg Black A6-3430M
Specifications
34 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 1.7 GHz |
| Processor family | AMD A6 |
| Processor model | A6-3430M |
| Processor cores | 4 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR3-SDRAM |
| Memory layout (slots x size) | 1 x 4 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 32 GB |
| Storage media | SSD |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | AMD Radeon HD 6520G |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| DisplayPorts quantity | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Display included | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Embedded Standard 7 |
Power
| Specification | Value |
|---|---|
| Power supply | 70 W |
| Power consumption (typical) | 27 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC class A, CE, VCCI, KCC, BSMI, C-Tick , CCC UL/c-UL, CSA, TUV, NEMKO, KC, CCC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 175.6 mm |
| Height | 34.4 mm |
| Weight | 1.2 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 430 mm |
| Package depth | 250 mm |
| Package height | 55 mm |
| Package weight | 1.9 kg |
