t5740e 1.66 GHz Windows 7 Embedded 1.58 kg N280
Model t5740ePart no. A1U70AAEAN 885631635360
30 specifications
- ProcessorIntel Atom®
- Memory2 GB
- Storage4 GB
- OSWindows 7 Embedded
- Weight1.58 kg
- Processor frequency1.66 GHz
Overview
- Processor
- Intel Atom®
- Memory
- 2 GB
- Storage
- 4 GB
- OS
- Windows 7 Embedded
- Weight
- 1.58 kg
- Processor frequency
- 1.66 GHz
- Brand
- HP
- Category
- Thin Client
- Model
- t5740e
- Part numbers
- A1U70AA, XL424AT, XL425AA, XL424AA, A1U69AA
- EAN / UPC
- 885631635360, 885631635568, 885631635575, 885631635582 +56 more
- Also known as
- HP t5740e 1.66 GHz Windows 7 Embedded 1.58 kg N280
Specifications
30 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 1.66 GHz |
| Processor family | Intel Atom® |
| Processor model | N280 |
| Processor front side bus | 667 MHz |
| L2 cache | 0.512 MB |
| Motherboard chipset | Intel® GL40 Express |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 4 GB |
Audio
| Specification | Value |
|---|---|
| Number of built-in speakers | 1 |
| Audio system | 16-bit stereo |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 6 |
| USB 2.0 ports quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| DisplayPorts quantity | 1 |
| Serial ports quantity | 1 |
| PS/2 ports quantity | 2 |
Display
| Specification | Value |
|---|---|
| Display included | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 7 Embedded |
Power
| Specification | Value |
|---|---|
| Power supply | 65 W |
Certificates
| Specification | Value |
|---|---|
| Country of origin | China |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.58 kg |
Other features
| Specification | Value |
|---|---|
| Compatible operating systems | Citrix XenApp 5 and 6 Citrix XenDesktop 3 and 4 Citrix Presentation Server 4.0 Windows Server 2008 Terminal Services Windows 2000/2003 Server families, Windows 2000/2003 Server Terminal Services VMware Virtual Desktop Infrastructure using RDP |
| Dimensions (W x D x H) with stand | 44 x 222 x 255 mm |
| Graphics card | GMA 4500M |
| Graphics card family | Intel |
| Networking features | Gigabit Ethernet |
| Power requirements | 100-240 VAC, 50-60 Hz |
| Supported network protocols | TCP/IP (DNS & DHCP), PPP, PPPoE, PPTP, L2TP, WOL, STNP, SNMP |
