Elite t655 TC R2314 16GB 256GB (ML)
Model Elite t655 TC R2314 16GB 256GB (ML)Part no. 5H128EA#UUWEAN 198990591391
58 specifications
- ProcessorAMD Ryzen Embedded
- Memory16 GB
- Storage256 GB
- SpeedWi-Fi 6 (802.11ax)
- OSWindows 11 IoT Enterprise
- Weight1.12 kg
Overview
- Processor
- AMD Ryzen Embedded
- Memory
- 16 GB
- Storage
- 256 GB
- Speed
- Wi-Fi 6 (802.11ax)
- OS
- Windows 11 IoT Enterprise
- Weight
- 1.12 kg
- Brand
- HP
- Category
- Thin Client
- Model
- Elite t655 TC R2314 16GB 256GB (ML)
- Part numbers
- 5H128EA#UUW, 5H126EA#UUW
- EAN / UPC
- 198990591391, 198990592190
- Also known as
- HP Elite t655 TC R2314 16GB 256GB (ML) 2.1 GHz Windows 11 IoT Enterprise 1.12 kg Black
Specifications
58 specifications in 16 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 2.1 GHz |
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen Embedded |
| Processor generation | AMD Ryzen Embedded R2000 Series |
| Processor model | R2314 |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor boost frequency | 3.5 GHz |
| Processor cache | 2 MB |
| L2 cache | 2 MB |
| L3 cache | 4 MB |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Memory slots | 2x SO-DIMM |
| Memory layout (slots x size) | 2 x 8 GB |
| Maximum internal memory | 32 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 256 GB |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Storage drive interface | PCI Express |
| NVMe | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board GPU manufacturer | AMD |
| On-board graphics card model | AMD Radeon Graphics |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Realtek |
| WLAN controller model | Realtek RTL8852BE |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Combo headphone/mic port | Yes |
| DisplayPorts quantity | 3 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Display included | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 IoT Enterprise |
Power
| Specification | Value |
|---|---|
| Power supply | 45 W |
Certificates
| Specification | Value |
|---|---|
| Country of origin | China |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | TCO |
| Sustainable technologies and materials | Low Halogen |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 35 mm |
| Depth | 200 mm |
| Height | 200 mm |
| Weight | 1.12 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
| Keyboard included | Yes |
| Keyboard connectivity | Wired |
| Mouse connectivity | Wired |
Other features
| Specification | Value |
|---|---|
| Keyboard type | USB |
| UNSPSC-code | 43211506 |
