365W NeON Prime High Efficiency
Model 365W NeON Prime High EfficiencyPart no. LG365Q1K-V5
43 specifications
- Power275 W
- Weight17.5 kg
- ColourBlack
- Solar cell typeMonocrystalline silicon
- Operating temperature (T-T)-40 - 90 °C
- Width1016 mm
Overview
- Power
- 275 W
- Weight
- 17.5 kg
- Colour
- Black
- Solar cell type
- Monocrystalline silicon
- Operating temperature (T-T)
- -40 - 90 °C
- Width
- 1016 mm
- Brand
- LG
- Category
- Solar Panel
- Model
- 365W NeON Prime High Efficiency
- Part number
- LG365Q1K-V5
- Also known as
- LG 365W NeON Prime High Efficiency solar panel 275 W Monocrystalline silicon
Specifications
43 specifications in 6 groups
Power
| Specification | Value |
|---|---|
| Rated power | 275 W |
| Current at maximum power (Imp) | 7.47 A |
| Fuse rating | 20 |
| Maximum system voltage | 1000 V |
| Short-circuit current (Isc) | 8.5 A |
| Voltage at maximum power (Vmp) | 36.8 V |
| Voltage at open-circuit (Voc) | 41 V |
| MPP Current (NMOT) | 7.47 A |
| MPP Voltage (NMOT) | 36.8 V |
| Maximum Power (STC) | 365 W |
| MPP Current (STC) | 9.9 A |
| Short-circuit current (Isc) (STC) | 10.55 A |
| Power tolerance (STC) | 3% |
| MPP Voltage (STC) | 36.9 V |
| Open-circuit voltage (STC) | 43.5 V |
Features
| Specification | Value |
|---|---|
| Solar cell type | Monocrystalline silicon |
| Connector type | MC4 |
| Product colour | Black |
| Housing material | Tempered glass |
| Housing thickness | 2.8 mm |
| Frame | Yes |
| Frame material | Anodized aluminium |
| Anti-reflective coating | Yes |
| International Protection (IP) code | IP68 |
| Fire-resistance rating | Class C (UL 790) |
| Fire-resistant | Yes |
| Certification | IEC 61215-1/-1-1/-2:2016, IEC 61730-1/2:2016, UL 1703, ISO 9001, ISO 14001, ISO 50001, OHSAS 18001 |
| Ammonia corrosion test | IEC 62716:2013 |
| Salt mist corrosion test | IEC 61701:2012 Severity 6 |
| Mechanical test load (Front) (Pa/psf) | 5400/113 |
| Mechanical test load (Rear) (Pa/psf) | 4000/84 |
| Module fire performance | Type 2 |
| Cable length | 1 m |
| Number of cells | 60 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 90 °C |
Logistics data
| Specification | Value |
|---|---|
| Products per intermodal container (40ft) | 650 pc(s) |
| Products per pallet | 25 pc(s) |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
| Package gross weight | 473 kg |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1016 mm |
| Depth | 1700 mm |
| Height | 40 mm |
| Weight | 17.5 kg |
