1 Port Industrial RS-232 / 422 / 485 Serial to IP Ethernet Device Server
2x 10/100Mbps Ports
Model NETRS232485EAN 065030854559
38 specifications
- Weight329 g
- ColourBlack
- Serial ports quantity1
- Ethernet LAN (RJ-45) ports2
- Input voltage12 - 48 V
- Link/Act LEDYes
Overview
- Weight
- 329 g
- Colour
- Black
- Serial ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 2
- Input voltage
- 12 - 48 V
- Link/Act LED
- Yes
- Brand
- StarTech.com
- Category
- Serial Server
- Model
- NETRS232485
- Part number
- NETRS232485
- EAN / UPC
- 065030854559, 533302043210, 676753234759, 4058829137878
- Also known as
- StarTech.com 1 Port Industrial RS-232 / 422 / 485 Serial to IP Ethernet Device Server - 2x 10/100Mbps Ports
Specifications
38 specifications in 11 groups
Technical details
| Specification | Value |
|---|---|
| Serial ports quantity | 1 |
| Auto MDI/MDI-X | Yes |
| Baud rate | 460.8 Kbit/s |
| Compliance certificates | RoHS |
| Data bits | 5, 6, 7, 8 |
| Data transfer rate | 0.46 Mbit/s |
| Electrostatic Discharge (ESD) protection (air) | 8 kV |
| Electrostatic Discharge (ESD) protection (contact) | 4 kV |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Flow Control type | RTS/CTS, XON/XOFF |
| Flow control support | Yes |
| Mean time between failures (MTBF) | 533615 h |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Serial interface type | RS-232/422/485 |
| Certification | CE, FCC |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100Base-T(X) |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Steel |
| International Protection (IP) code | IP30 |
Power
| Specification | Value |
|---|---|
| Input voltage | 12 - 48 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 329 g |
| Dimensions (WxDxH) | 127 x 72 x 31 mm |
| Package width | 153 mm |
| Package length | 19.8 cm |
| Package height | 48 mm |
| Package weight | 504 g |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win |
| Server operating systems supported | Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012 |
Indication
| Specification | Value |
|---|---|
| Link/Act LED | Yes |
| Power LED | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
Packaging content
| Specification | Value |
|---|---|
| User guide | Yes |
| Wall mounting kit | Yes |
Protocols
| Specification | Value |
|---|---|
| Supported network protocols | ICMP, IP, TCP, UDP, DHCP, BOOTP, SSH, DNS, SNMP V1/V2c, HTTPS, SMTP, SSL, PPPoE, DDNS |
Security
| Specification | Value |
|---|---|
| Security algorithms | 128-bit WEP, SSL/TLS |
