SN3402P serial server RS-232/422/485
Model SN3402PEAN 672792013386
51 specifications
- Weight220 g
- ColourBlack
- Serial ports quantity2
- Ethernet LANYes
- LED indicatorsPower, Status
- Power source typeDC, PoE
Overview
- Weight
- 220 g
- Colour
- Black
- Serial ports quantity
- 2
- Ethernet LAN
- Yes
- LED indicators
- Power, Status
- Power source type
- DC, PoE
- Brand
- ATEN
- Category
- Serial Server
- Model
- SN3402P
- Part numbers
- SN3402P, SN3402P-AX
- EAN / UPC
- 672792013386, 4710469341571
- Also known as
- ATEN SN3402P serial server RS-232/422/485
Specifications
51 specifications in 10 groups
Technical details
| Specification | Value |
|---|---|
| Serial ports quantity | 2 |
| Baud rate | 921.6 Kbit/s |
| Compliance certificates | RoHS |
| Data bits | 5, 6, 7, 8 |
| Data transfer rate | 100 Mbit/s |
| Electrostatic Discharge (ESD) protection | 8 kV |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Flow Control type | DTR/DSR, RTS/CTS, XON/XOFF |
| Flow control support | Yes |
| Isolation | 1.5 kV |
| Networking standards | IEEE 802.3af |
| Parity bit | Even, Mark, No, Odd, Space |
| RS-232 signals | CTS, DCD, DSR, DTR, GND, RTS, RXD, TXD |
| RS-422 signals | GND, RxD+, RxD-, TxD+, TxD- |
| RS-485 signals | Data+, Data-, GND, RxD+, RxD-, TxD+, TxD- |
| Serial interface type | RS-232/422/485 |
| Stop bits | 1, 1.5, 2 |
| Surge protection voltage | 2 kV |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Terminal block port | Yes |
Indication
| Specification | Value |
|---|---|
| LED indicators | Power, Status |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| Reset button | Yes |
| DIN rail mounting | Yes |
| Safety | UL 60950-1, UL 62368-1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC, PoE |
| Power consumption (max) | 1.3 W |
| Power consumption (typical) | 1.19 W |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Output voltage | 9 - 48 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 117 mm |
| Depth | 98 mm |
| Height | 26 mm |
| Weight | 220 g |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 430 g |
Packaging content
| Specification | Value |
|---|---|
| DIN rail kit included | Yes |
| Terminal block included | Yes |
| Number of foot pads | 4 pc(s) |
| User guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -40 - 75 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | UL ECOLOGO |
| Sustainability compliance | Yes |
