1-Port Serial-to-IP Ethernet Device Server - RS232 - DIN Rail Mountable
Model NETRS232EAN 8502201629940
45 specifications
- Weight68 g
- ColourBlack
- Serial ports quantity1
- LED indicatorsActivity, Link, Power
- Input voltage100 - 240 V
- Linux operating systems supportedYes
Overview
- Weight
- 68 g
- Colour
- Black
- Serial ports quantity
- 1
- LED indicators
- Activity, Link, Power
- Input voltage
- 100 - 240 V
- Linux operating systems supported
- Yes
- Brand
- StarTech.com
- Category
- Serial Server
- Model
- NETRS232
- Part number
- NETRS232
- EAN / UPC
- 8502201629940, 065030857161, 650308571612, 723856592801 +7 more
- Also known as
- StarTech.com 1-Port Serial-to-IP Ethernet Device Server - RS232 - DIN Rail Mountable
Specifications
45 specifications in 11 groups
Technical details
| Specification | Value |
|---|---|
| Serial ports quantity | 1 |
| Auto MDI/MDI-X | Yes |
| Baud rate | 230.4 Kbit/s |
| Compliance certificates | RoHS |
| Data bits | 5, 6, 7, 8 |
| Flow Control type | No, RTS/CTS |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Parity bit | Even, Mark, No, Odd, Space |
| Serial interface type | RS-232 |
| Stop bits | 1, 1.5, 2 |
| Surge protection voltage | 15 kV |
| Certification | CE, FCC, TAA, PSE, REACH |
| Remote management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
| Cabling technology | 10/100Base-T(X) |
Indication
| Specification | Value |
|---|---|
| LED indicators | Activity, Link, Power |
| Link/Act LED | Yes |
| Power LED | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Plastic |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Output voltage | 12 V |
| Output current | 1.2 A |
| Compatible power plug types | AU, EU, UK, US |
| Input current | 0.5 A |
| Power plug type | Type H |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 68 g |
| Dimensions (WxDxH) | 55 x 95 x 22 mm |
| Package width | 159 mm |
| Package depth | 175 mm |
| Package height | 76 mm |
| Package weight | 444 g |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windo |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 12 pc(s) |
| Master (outer) case length | 394 mm |
| Master (outer) case width | 330 mm |
| Master (outer) case height | 271 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -10 - 70 °C |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
Protocols
| Specification | Value |
|---|---|
| Supported network protocols | VCOM, TCP Server, TCP Client, UDP, HTTP, DHCP, ICMP(PING), Static IP, ARP, Telnet |
