SN0116A serial server RS-232
Model SN0116APart no. SN0116A-AX-GEAN 4719264643262
24 specifications
- Weight4.38 kg
- ColourBlack
- Serial ports quantity16
- USB 2.0 ports quantity3
- LED indicatorsLAN, Power, Status
- Power source typeAC
Overview
- Weight
- 4.38 kg
- Colour
- Black
- Serial ports quantity
- 16
- USB 2.0 ports quantity
- 3
- LED indicators
- LAN, Power, Status
- Power source type
- AC
- Brand
- ATEN
- Category
- Serial Server
- Model
- SN0116A
- Part numbers
- SN0116A-AX-G, SN0116A
- EAN / UPC
- 4719264643262, 672792403361
- Also known as
- ATEN SN0116A serial server RS-232
Specifications
24 specifications in 10 groups
Technical details
| Specification | Value |
|---|---|
| Serial ports quantity | 16 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Serial interface type | RS-232 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100/1000Base-T(X) |
Indication
| Specification | Value |
|---|---|
| LED indicators | LAN, Power, Status |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Output current | 1 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 4.38 kg |
| Dimensions (WxDxH) | 329.8 x 437.2 x 44 mm |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Ba |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| User guide | Yes |
| Wall mounting kit | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | HTTPS, SMTP-AUTH, SNMP, SSH, SSL/TLS |
