33307E serial converter/repeater/isolator USB 2.0 RS-232 Black

33307E serial converter/repeater/isolator USB 2.0 RS-232 Black

Model 33307EEAN 4043718353163

29 specifications

Weight14 g
ColourBlack
Host interfaceUSB 2.0
Width22 mm
Mac compatibilityYes
Operating relative humidity (H-H)5 - 95%

See all specifications

Overview

Weight: 14 g
Colour: Black
Host interface: USB 2.0
Width: 22 mm
Mac compatibility: Yes
Operating relative humidity (H-H): 5 - 95%

Brand: InLine
Category: Serial Converters/Repeaters/Isolators
Model: 33307E
Part number: 33307E
EAN / UPC: 4043718353163
Also known as: InLine 33307E serial converter/repeater/isolator USB 2.0 RS-232 Black

Specifications

29 specifications in 6 groups

Technical details

Specification	Value
Host interface	USB 2.0
Output interface	RS-232
Connector 1	USB Type-A
Connector 2	Terminal block
Connector gender	Male/Female
Baud rate	512 Kbit/s
Chipset	FTDI FT232RNL
Electrostatic Discharge (ESD) protection	15 kV
Isolation	2.5 kV
Package volume	400 cm³
Product colour	Black
RS-232 signals	GND, Tx, Rx
RS-485 signals	GND

Weight & dimensions

Specification	Value
Width	22 mm
Depth	78 mm
Height	11 mm
Weight	14 g
Package width	100 mm
Package depth	165 mm
Package height	22 mm
Package weight	33 g
Dimensions (WxDxH)	22 x 78 x 11 mm

Software

Specification	Value
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows 11, Windows 10, Windows XP
Mac compatibility	Yes
Mac operating systems supported	MacOS

Logistics data

Specification	Value
Country of origin	China

Operational conditions

Specification	Value
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-15 - 70 °C

Packaging content

Specification	Value
Package type	Polybag
