Pro SD59225I-HC security camera Bullet CCTV security camera
1920 x 1080 pixels Ceiling
Model SD59225I-HCEAN 6939554942440
71 specifications
- ConnectivityWired
- TypeCCTV security camera
- ColourWhite
- Form factorBullet
- Camera pan controlYes
- Sensor typeCMOS
Overview
- Connectivity
- Wired
- Type
- CCTV security camera
- Colour
- White
- Form factor
- Bullet
- Camera pan control
- Yes
- Sensor type
- CMOS
- Brand
- Dahua Technology
- Category
- Security Camera
- Model
- SD59225I-HC
- Part number
- SD59225I-HC
- EAN / UPC
- 6939554942440
- Also known as
- Dahua Technology Pro SD59225I-HC security camera Bullet CCTV security camera 1920 x 1080 pixels Ceiling
Specifications
71 specifications in 16 groups
Performance
| Specification | Value |
|---|---|
| Type | CCTV security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| PTZ modes | 5 Pattern, 8 Tour, Auto scan, Auto pan |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Certification | CE, FCC, UL |
Design
| Specification | Value |
|---|---|
| Form factor | Bullet |
| Mounting type | Ceiling |
| Product colour | White |
| Housing material | Metal |
| International Protection (IP) code | IP66 |
Camera
| Specification | Value |
|---|---|
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Minimum illumination | 0 lx |
| Tilt angle range | -15 - 90° |
| Pan range | 0 - 360° |
| Auto flip | Yes |
| White balance | ATW, Auto, Indoor, Manual, Outdoor |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/30000 s |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Number of effective pixels (H x V) | 1920 x 1080 pixels |
Lens system
| Specification | Value |
|---|---|
| Optical zoom | 25x |
| Digital zoom | 16x |
| Detect distance | 1613 m |
| Observe distance | 646 m |
| Recognize distance | 323 m |
| Focal length range | 4.8 - 120 mm |
| Auto focus | Yes |
| Focus | Motorized/Manual |
| Identify distance | 161 m |
| Maximum aperture number | 4.4 |
| Minimum aperture number | 1.6 |
| Closest focusing distance | 0.1 m |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 150 m |
| LED type | IR |
| Number of illumination LEDs | 4 |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Supported video modes | 720p, 1080p |
| Frame rate | 60 fps |
| Noise reduction | Yes |
| Noise reduction technology | Ultra 2D noise reduction, Ultra 3D noise reduction |
| Gain control type | Auto/Manual |
| Back Light Compensation (BLC) | Yes |
| Flip & mirror | Yes |
| Highlight Compensation (HLC) | Yes |
| Privacy masking | Yes |
Audio
| Specification | Value |
|---|---|
| Audio input channels | 1.0 channels |
| Signal-to-Noise Ratio (SNR) | 55 dB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
| Bluetooth | No |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
Ports & interfaces
| Specification | Value |
|---|---|
| RS-485 ports | 1 |
| Composite video out | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 24 V |
| Power consumption (typical) | 13 W |
| Power consumption (max) | 23 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Height | 309 mm |
| Diameter | 18.6 cm |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 7.2 kg |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
