Dahua Technology SD2A200HB-GN-AW-PV-S2 security camera Turret IP security camera Outdoor
Dahua Technology

SD2A200HB-GN-AW-PV-S2 security camera Turret IP security camera Outdoor

1920 x 1080 pixels Ceiling

Model SD2A200HB-GN-AW-PV-S2

74 specifications
  • Memory128 MB
  • ConnectivityWired & Wireless
  • TypeIP security camera
  • Weight500 g
  • ColourWhite
  • Form factorTurret
See all specifications

Overview

Memory
128 MB
Connectivity
Wired & Wireless
Type
IP security camera
Weight
500 g
Colour
White
Form factor
Turret
Brand
Dahua Technology
Model
SD2A200HB-GN-AW-PV-S2
Part number
SD2A200HB-GN-AW-PV-S2
Also known as
Dahua Technology SD2A200HB-GN-AW-PV-S2 security camera Turret IP security camera Outdoor 1920 x 1080 pixels Ceiling

Specifications

74 specifications in 17 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired & Wireless
PTZ controlYes
Preset pointsYes
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
Built-in lightYes
Antenna typeExternal
Antennas quantity2

Design

Form factorTurret
Mounting typeCeiling
Product colourWhite
International Protection (IP) codeIP66

Camera

Camera pan controlYes
Camera tilt controlYes
Minimum illumination0 lx
Tilt angle range0 - 80°
Tilt speed36.3 °/sec
Pan range0 - 345°
Pan speed62 °/sec

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Progressive scanYes

Lens system

Number of lenses1
Detect distance53.6 m
Observe distance21.4 m
Recognize distance10.7 m
Identify distance5.4 m
Maximum aperture number2
Fixed focal length4 mm

Night vision

Night visionYes
Night vision distance30 m
LED typeIR/White
Number of illumination LEDs4

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video streamingYes
Noise reductionYes
Noise reduction technology2D noise reduction, 3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rateH265: 144–5632 kpbs
Highlight Compensation (HLC)Yes

Audio

Built-in speaker(s)Yes
Audio system2-way
Signal-to-Noise Ratio (SNR)55 dB
Built-in microphoneYes

Network

Ethernet LANYes
Wi-FiYes
Ethernet interface typeFast Ethernet, Gigabit Ethernet
Supported network protocolsUDP; FTP; RTMP; IPv6; IPv4; IP Filter; DNS; RTCP; HTTP; NTP; SSL; DHCP; RTP; SMTP; HTTPS; TCP/IP; RTSP; DDNS; ARP
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of users20 user(s)

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
ROM capacity128 MB
RAM capacity128 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Security

Active tampering alarmYes

Management features

Web-based managementYes

Power

Power source typeDC
Power consumption (typical)3.5 W
Power consumption (max)11 W
DC output voltage12
DC output current1.5 A

Weight & dimensions

Diameter11.1 cm
Length140.5 mm
Weight500 g

Packaging data

Package weight1 kg

Packaging content

Number of cameras1
