Dahua Technology IPC-HPT1539DD-STW-5E2 security camera Turret IP security camera Indoor

Dahua Technology

IPC-HPT1539DD-STW-5E2 security camera Turret IP security camera Indoor

2880 x 1620 pixels Desk

Model IPC-HPT1539DD-STW-5E2

75 specifications

ConnectivityWired & Wireless
TypeIP security camera
Weight233 g
ColourWhite
Form factorTurret
Camera pan controlYes

See all specifications

Overview

Connectivity: Wired & Wireless
Type: IP security camera
Weight: 233 g
Colour: White
Form factor: Turret
Camera pan control: Yes

Brand: Dahua Technology
Category: Security Camera
Model: IPC-HPT1539DD-STW-5E2
Part number: IPC-HPT1539DD-STW-5E2
Also known as: Dahua Technology IPC-HPT1539DD-STW-5E2 security camera Turret IP security camera Indoor 2880 x 1620 pixels Desk

Specifications

75 specifications in 19 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
PTZ control	Yes
Auto-tracking	Yes
Day/night mode	Yes
Built-in light	Yes
Antenna type	Internal

Design

Specification	Value
Form factor	Turret
Mounting type	Desk
Product colour	White
Housing material	Plastic

Camera

Specification	Value
Camera pan control	Yes
Camera tilt control	Yes
Angle of rotation	180°
Lens viewing angle, horizontal	86°
Lens viewing angle, vertical	46°
Lens viewing angle, diagonal	104°
Tilt angle range	-5 - 90°
Pan range	0 - 349°

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 3 mm (1 / 3")

Lens system

Specification	Value
Number of lenses	2
Fixed focus	Yes
Maximum aperture number	2
Fixed focal length	3.6 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	30 m
B/W night vision distance	30 m
LED type	IR/White
Number of illumination LEDs	1

Video

Specification	Value
Maximum resolution	2880 x 1620 pixels
Total megapixels	10 MP
Video formats supported	H.265
Video compression formats	H.265
Supported graphics resolutions	640 x 360, 2880 x 1620
Video recording	Yes
Frame rate	15 fps
Bit rate	768 kbps - 4096 kbps
Digital Wide Dynamic Range (DWDR)	Yes

Audio

Specification	Value
Built-in speaker(s)	Yes
Built-in microphone	Yes
Voice codecs	G.711a

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes
Ethernet interface type	Fast Ethernet
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB port	Yes

Security

Specification	Value
Built-in siren	Yes
Intelligent Video Surveillance (IVS) system features	Human detection, Pet detection
Privacy protection	Yes
Video motion detection	Yes

Management features

Specification	Value
Management software	DMSS

Power

Specification	Value
Power source type	USB
Power consumption (typical)	2.5 W
Power consumption (max)	5.4 W
DC output voltage	5

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	0 - 95%

System requirements

Specification	Value
Mobile operating systems supported	Android, iOS

Weight & dimensions

Specification	Value
Height	125.7 mm
Diameter	8.09 cm
Weight	233 g

Sustainability

Specification	Value
Compliance certificates	CE

Packaging content

Specification	Value
Number of cameras	1
Screws included	Yes
AC adapter included	Yes
Quick start guide	Yes
USB charger included	Yes
