Dahua Technology WizMind IPC-HDBW5559E1-ZHE-IL-27135-Black Dome IP security camera Outdoor
Dahua Technology

WizMind IPC-HDBW5559E1-ZHE-IL-27135-Black Dome IP security camera Outdoor

2960 x 1668 pixels Ceiling/Wall/Pole

Model IPC-HDBW5559E1-ZHE-IL-27135-BlackPart no. IPC-HDBW5559E1-ZHE-IL-27135-BLACKEAN 6937552412804

102 specifications
  • Memory2048 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight1.16 kg
  • ColourBlack
  • Form factorDome
See all specifications

Overview

Memory
2048 MB
Connectivity
Wired
Type
IP security camera
Weight
1.16 kg
Colour
Black
Form factor
Dome
Brand
Dahua Technology
Model
IPC-HDBW5559E1-ZHE-IL-27135-Black
Part number
IPC-HDBW5559E1-ZHE-IL-27135-BLACK
EAN / UPC
6937552412804
Also known as
Dahua Technology WizMind IPC-HDBW5559E1-ZHE-IL-27135-Black Dome IP security camera Outdoor 2960 x 1668 pixels Ceiling/Wall/Pole

Specifications

102 specifications in 19 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired
People counting functionYes
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
Dynamic range120 dB

Design

Form factorDome
Mounting typeCeiling/Wall/Pole
Product colourBlack
Housing materialMetal
Protection featuresVandal proof
International Protection (IP) codeIP67
IK codeIK10

Camera

Camera pan controlYes
Camera tilt controlYes
Minimum illumination0.0005 lx
Angle of rotation355°
Lens viewing angle, horizontal110 - 32°
Lens viewing angle, vertical57 - 18°
Lens viewing angle, diagonal134 - 37°
Tilt angle range0 - 80°
Pan range0 - 355°
White balanceAuto, Natural, Street lamp, Outdoor, Manual, Regional custom
Camera shutter speed1/3 - 1/100000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.7 mm (1 / 2.7")
Progressive scanYes

Lens system

Focal length range2.7 - 13.5 mm
Maximum aperture number1.6
Closest focusing distance0.3 m
Detect distance (tele)202 m
Detect distance (wide)65.4 m
Identify distance (tele)20.2 m
Identify distance (wide)6.5 m
Observe distance (tele)80.8 m
Observe distance (wide)26.1 m
Recognize distance (tele)40.4 m
Recognize distance (wide)13.1 m

Night vision

Night visionYes
Night vision distance60 m
LED typeIR
Number of illumination LEDs4

Video

Maximum resolution2960 x 1668 pixels
Total megapixels5 MP
Video compression formatsH.264, H.265, H.264H, H.264B, M-JPEG
Video recordingYes
Frame rate30 fps
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Image stabilizerYes
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rate controlConstant Bit Rate (CBR), Variable Bit Rate (VBR)
Highlight Compensation (HLC)Yes
Region of Interest (ROI) encodingYes
Smart IRYes

Audio

Audio formats supportedG.711 A-law, G.711 μ-law, G.723, G.726, PCM
Signal-to-Noise Ratio (SNR)56 dB
Built-in microphoneYes

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.1x, IEEE 802.3at
Supported network protocolsIPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
Number of users20 user(s)
Quality of Service (QoS) supportYes
Streaming methodMulticast

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size1 TB
ROM capacity4096 MB
RAM capacity2048 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
DC-in jackYes

Security

Alarm input channels2
Alarm output channels1
Digital watermarkYes
HTTPS encryptionYes
Human and vehicle targets classificationYes
Intelligent Video Surveillance (IVS) system featuresTripwire, Intrusion, People counting
MirrorYes
Network access storage (NAS)Yes
Video motion detectionYes

Power

Power source typePoE, DC
Power consumption (typical)3.7 W
Power consumption (max)12.9 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-40 - 60 °C
Storage temperature (T-T)-40 - 60 °C

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Height118 mm
Diameter15.9 cm
Weight1.16 kg

Sustainability

Compliance certificatesCE

Packaging data

Package weight1.36 kg

Packaging content

Number of cameras1
ManualYes
