Dahua Technology Lite HAC-HFW1809TLMN-A-LED-0280B-S0 Bullet CCTV security camera Outdoor

Dahua Technology Lite HAC-HFW1809TLMN-A-LED-0280B-S0 Bullet CCTV security camera Outdoor

3840 x 2160 pixels Ceiling/Wall/Pole

Model HAC-HFW1809TLMN-A-LED-0280B-S0Part no. DH-HAC-HFW1809TLMN-A-LED-0280B-S0

68 specifications
  • ConnectivityWired
  • TypeCCTV security camera
  • Weight330 g
  • ColourWhite
  • Form factorBullet
  • Minimum illumination0 lx
See all specifications

Overview

Connectivity
Wired
Type
CCTV security camera
Weight
330 g
Colour
White
Form factor
Bullet
Minimum illumination
0 lx
Brand
Dahua Technology
Model
HAC-HFW1809TLMN-A-LED-0280B-S0
Part number
DH-HAC-HFW1809TLMN-A-LED-0280B-S0
Also known as
Dahua Technology Lite HAC-HFW1809TLMN-A-LED-0280B-S0 Bullet CCTV security camera Outdoor 3840 x 2160 pixels Ceiling/Wall/Pole

Specifications

68 specifications in 18 groups

Performance

TypeCCTV security camera
Placement supportedOutdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Dynamic range120 dB
CertificationCE (EN55032:2015, EN61000-3-2:2014, EN61000- 3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14)

Design

Form factorBullet
Mounting typeCeiling/Wall/Pole
Product colourWhite
Housing materialMetal, Plastic
International Protection (IP) codeIP67

Camera

Minimum illumination0 lx
Angle of rotation360°
Lens viewing angle, horizontal106°
Lens viewing angle, vertical55°
Lens viewing angle, diagonal125°
Tilt angle range0 - 90°
Pan range0 - 360°
White balanceArea white balance, Auto
Camera shutter typeElectronic
Camera shutter speed1/4 - 1/100000 s

Image sensor

Sensor typeCMOS
Progressive scanYes

Lens system

Number of lenses1
Zoom capabilityYes
Digital zoom4x
Detect distance91 m
Observe distance36.4 m
Recognize distance18.2 m
Identify distance9.1 m
Minimum aperture number1
Closest focusing distance3.5 m
Fixed focal length2.8 mm

Night vision

Night visionYes
LED typeWhite
Number of illumination LEDs2

Video

Maximum resolution3840 x 2160 pixels
Total megapixels8 MP
Supported graphics resolutions960 x 480, 960 x 576, 2560 x 1440, 2880 x 1620, 3840 x 2160
Frame rate30 fps
Analog signal format systemNTSC
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto
Back Light Compensation (BLC)Yes
Highlight Compensation (HLC)Yes
Privacy maskingYes

Audio

Signal-to-Noise Ratio (SNR)65 dB
Built-in microphoneYes

Network

Ethernet LANNo
Wi-FiNo
BluetoothNo

Storage

Built-in HDDNo

Ports & interfaces

BNC output ports1

Security

MirrorYes

Management features

Cloud-managedNo

Power

Power source typeDC
Power consumption (max)6.9 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-40 - 60 °C
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth80.2 mm
Height76.2 mm
Length198.4 mm
Weight330 g

Packaging data

Package weight490 g

Packaging content

Number of cameras1
