Dahua Technology DHI-MNVR4208-GFWI + DH-IPC-HDBW3231FN-M + MC-PF3-B3-4

Dahua Technology DHI-MNVR4208-GFWI + DH-IPC-HDBW3231FN-M + MC-PF3-B3-4

Model DHI-MNVR4208-GFWI + DH-IPC-HDBW3231FN-M + MC-PF3-B3-4Part no. DAHUA PAQUETE IP MÓVIL

83 specifications
  • Memory256 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight330 g
  • ColourBlack, White
  • Form factorDome
See all specifications

Overview

Memory
256 MB
Connectivity
Wired
Type
IP security camera
Weight
330 g
Colour
Black, White
Form factor
Dome
Brand
Dahua Technology
Model
DHI-MNVR4208-GFWI + DH-IPC-HDBW3231FN-M + MC-PF3-B3-4
Part number
DAHUA PAQUETE IP MÓVIL
Also known as
Dahua Technology DHI-MNVR4208-GFWI + DH-IPC-HDBW3231FN-M + MC-PF3-B3-4 Dome IP security camera Indoor & outdoor 1920 x 1080 pixels Ceiling/Wall/Pole

Specifications

83 specifications in 18 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
CertificationCE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B EN50155(Environment)

Design

Form factorDome
Mounting typeCeiling/Wall/Pole
Product colourBlack, White
Housing materialMetal
International Protection (IP) codeIP67
IK codeIK10

Camera

Camera pan controlYes
Camera tilt controlYes
Minimum illumination0.001 lx
Angle of rotation360°
Lens viewing angle, horizontal110°
Lens viewing angle, vertical58°
Tilt angle range0 - 80°
Pan range-30 - 30°
White balanceAuto, Manual
Camera shutter typeElectronic
Camera shutter speed1/3 - 1/100000 s
Adjustment shutter speedAuto/Manual

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Progressive scanYes
Number of effective pixels (H x V)1920 x 1080 pixels

Lens system

Zoom capabilityYes
Digital zoom16x
Focal length range2.8 mm
Maximum aperture number2.1
Closest focusing distance0.6 m

Night vision

Night visionYes
Night vision distance23 m
LED typeIR
Number of illumination LEDs10

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video compression formatsH.264H, H.265, M-JPEG
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Supported video modes720p, 1080p
Frame rate30 fps
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rate16Kbps - 10240Kbps
Bit rate controlConstant Bit Rate (CBR), Variable Bit Rate (VBR)
Highlight Compensation (HLC)Yes
Privacy maskingYes
Region of Interest (ROI) encodingYes
Smart IRYes

Audio

Signal-to-Noise Ratio (SNR)50 dB
Built-in microphoneYes
Voice codecsAAC, G.711Mu, G.711a

Network

Ethernet LANYes
Ethernet interface typeFast Ethernet
Supported network protocolsHTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP; FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP; NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;S NMP;TLS
Number of users20 user(s)
Streaming methodMulticast, Unicast

Storage

Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size128 GB
Internal memory256 MB
ROM capacity32 MB

Security

MirrorYes
Video motion detectionYes

Management features

Web browserYes
Management softwareSmart PSS, DSS, DMSS

Power

Power source typeDC, PoE
DC output voltage12

Operational conditions

Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Width106 mm
Height50.3 mm
Weight330 g

Packaging data

Package weight460 g

Packaging content

Number of cameras1
