Dahua Technology DH-SD6C3425GB-HNR-A-PV1 security camera Spherical IP security camera Indoor & outdoor
Dahua Technology

DH-SD6C3425GB-HNR-A-PV1 security camera Spherical IP security camera Indoor & outdoor

2560 x 1440 pixels Ceiling

Model DH-SD6C3425GB-HNR-A-PV1EAN 6923172589347

100 specifications
  • Memory1024 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight4.6 kg
  • ColourWhite
  • Form factorSpherical
See all specifications

Overview

Memory
1024 MB
Connectivity
Wired
Type
IP security camera
Weight
4.6 kg
Colour
White
Form factor
Spherical
Brand
Dahua Technology
Model
DH-SD6C3425GB-HNR-A-PV1
Part number
DH-SD6C3425GB-HNR-A-PV1
EAN / UPC
6923172589347
Also known as
Dahua Technology DH-SD6C3425GB-HNR-A-PV1 security camera Spherical IP security camera Indoor & outdoor 2560 x 1440 pixels Ceiling

Specifications

100 specifications in 18 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
PTZ controlYes
PTZ modes5 Pattern, 8 Tour, Auto scan, Preset point
PTZ protocolsDH-SD
Auto-trackingYes
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
Built-in lightYes

Design

Form factorSpherical
Mounting typeCeiling
Product colourWhite
International Protection (IP) codeIP66

Camera

Camera pan controlYes
Camera tilt controlYes
Minimum illumination0 lx
Lens viewing angle, horizontal51.9 - 3°
Lens viewing angle, vertical39.7 - 2.2°
Lens viewing angle, diagonal63.1 - 3.7°
Tilt angle range-20 - 90°
Tilt manual speed0 - 90 °/sec
Tilt preset speed150 °/sec
Pan range0 - 360°
Pan manual speed0 - 240 °/sec
Pan preset speed240 °/sec
White balanceAuto, Indoor, Manual, Natural, Outdoor, Sodium lamp, Street lamp
Camera shutter typeElectronic
Camera shutter speed1/1 - 1/30000 s
Number of Privacy masking areas24

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Progressive scanYes

Lens system

Zoom capabilityYes
Optical zoom25x
Digital zoom16x
Detect distance2500 m
Observe distance987.5 m
Recognize distance500 m
Focal length range5 - 125 mm
Auto focusYes
Identify distance250 m
Maximum aperture number3.6
Minimum aperture number1.6
Closest focusing distance0.1 m

Night vision

Night visionYes
Night vision distance150 m
LED typeIR/White
Number of illumination LEDs4

Video

Maximum resolution2560 x 1440 pixels
Total megapixels4 MP
Video compression formatsH.264, H.264+, H.264B, H.264H, H.265, H.265+, M-JPEG
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2304 x 1296, 2560 x 1440
Frame rate30 fps
Video streamingYes
Noise reductionYes
Noise reduction technology2D noise reduction, 3D noise reduction
Image stabilizerYes
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rateH264: 96 kbps–14848 kbps H265: 38 kbps–8960 kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC)Yes
Privacy maskingYes
Region of Interest (ROI) encodingYes

Audio

Audio input channels1.0 channels
Audio output channels1.0 channels
Audio formats supportedG.711 A-law, G.722.1, G.723, G.726, G.729
Signal-to-Noise Ratio (SNR)55 dB

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsFTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;8 02.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IG MP;HTTP;SSL;DHCP;SMTP;Qos;RTSP;ARP
Number of users20 user(s)
Streaming methodMulticast, Unicast

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size512 GB
Internal memory1024 MB
ROM capacity4096 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Security

Alarm input channels2
Alarm output channels1
Video motion detectionYes

Power

Power source typeDC, PoE
Power consumption (typical)13 W
Power consumption (max)23 W
DC output voltage24
DC output current2.5 A

Operational conditions

Operating temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)0 - 95%

Weight & dimensions

Height325.3 mm
Diameter20.2 cm
Weight4.6 kg

Sustainability

Compliance certificatesCE, Federal Communications Commission (FCC)

Packaging data

Package weight7.13 kg

Packaging content

Number of cameras1
