Dahua Technology HDCVI PTZ DH-HAC-ME1509HN-A-PV security camera Dome CCTV security camera Indoor & outdoor
Dahua Technology

HDCVI PTZ DH-HAC-ME1509HN-A-PV security camera Dome CCTV security camera Indoor & outdoor

2880 x 1620 pixels Ceiling/wall

Model DH-HAC-ME1509HN-A-PV

75 specifications
  • ConnectivityWired
  • TypeCCTV security camera
  • Weight700 g
  • ColourWhite
  • Form factorDome
  • Minimum illumination0.001 lx
See all specifications

Overview

Connectivity
Wired
Type
CCTV security camera
Weight
700 g
Colour
White
Form factor
Dome
Minimum illumination
0.001 lx
Brand
Dahua Technology
Model
DH-HAC-ME1509HN-A-PV
Part number
DH-HAC-ME1509HN-A-PV
Also known as
Dahua Technology HDCVI PTZ DH-HAC-ME1509HN-A-PV security camera Dome CCTV security camera Indoor & outdoor 2880 x 1620 pixels Ceiling/wall

Specifications

75 specifications in 20 groups

Performance

TypeCCTV security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
CertificationCE (EN55032:2015, EN61000-3-2: 2014, EN61000-3- 3: 2013, EN55024: 2010+A1: 2015, EN55035: 2017, EN50130-4: 2011+A1: 2014, EN62368-1: 2014+A11: 2017) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14)

Design

Form factorDome
Mounting typeCeiling/wall
Product colourWhite
Housing materialMetal
International Protection (IP) codeIP67

Camera

Minimum illumination0.001 lx
Angle of rotation360°
Tilt angle range0 - 78°
Pan range0 - 360°
White balanceAuto

Image sensor

Sensor typeCMOS
Number of sensors2
Progressive scanYes
Number of effective pixels (H x V)2880 x 1620 pixels

Panoramic camera

Number of Privacy masking areas (panoramic camera)8

Lens system

Number of lenses1
Detect distance78 m
Observe distance31.2 m
Recognize distance15.6 m
Focal length range2.8 mm
Identify distance7.8 m
Closest focusing distance2.2 m
Fixed focal length3.6 mm
Detect distance (2.8mm lens)66 m
Observe distance (2.8mm lens)26.4 m
Recognize distance (2.8mm lens)13.2 m
Identify distance (2.8mm lens)6.6 m

Night vision

Night visionYes
Night vision distance40 m
LED typeIR
Number of illumination LEDs2

Video

Maximum resolution2880 x 1620 pixels
Total megapixels5 MP
Supported graphics resolutions960 x 480, 960 x 576, 1920 x 1080 (HD 1080), 2560 x 1440, 2880 x 1620
Frame rate25 fps
Analog signal format systemNTSC, PAL
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Highlight Compensation (HLC)Yes
Privacy maskingYes
Smart IRYes

Audio

Signal-to-Noise Ratio (SNR)65 dB
Built-in microphoneYes

Network

Ethernet LANNo
Wi-FiNo
BluetoothNo

Storage

Built-in HDDNo

Ports & interfaces

BNC output ports1

Security

Alarm output channels1
MirrorYes

Power

Power source typeDC
Power consumption (max)10.5 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-40 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%

Weight & dimensions

Height110.9 mm
Diameter12.2 cm
Weight700 g

Packaging data

Package width165 mm
Package depth165 mm
Package height138 mm
Package weight960 g

Packaging content

Number of cameras1

Other features

F-number (relative aperture)1

Technical details

Lens mount interfaceM12
