10/100Mbps Ethernet to USB 2.0 Network LPR Print Server
Model PM1115U2EAN 065030855174
41 specifications
- Weight60 g
- ColourBlack
- InternalNo
- Network connection typeEthernet LAN
- Supported network protocolsLPR
- Ethernet LAN (RJ-45) ports1
Overview
- Weight
- 60 g
- Colour
- Black
- Internal
- No
- Network connection type
- Ethernet LAN
- Supported network protocols
- LPR
- Ethernet LAN (RJ-45) ports
- 1
- Brand
- StarTech.com
- Category
- Print Server
- Model
- PM1115U2
- Part number
- PM1115U2
- EAN / UPC
- 065030855174, 4058829153809, 5054242516015, 5054629989289
- Also known as
- StarTech.com 10/100Mbps Ethernet to USB 2.0 Network LPR Print Server
Specifications
41 specifications in 14 groups
Features
| Specification | Value |
|---|---|
| Internal | No |
| Product colour | Black |
| Built-in display | No |
| LED indicators | Activity, Link, Power |
| Power LED | Yes |
Network
| Specification | Value |
|---|---|
| Network connection type | Ethernet LAN |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
Protocols
| Specification | Value |
|---|---|
| Supported network protocols | LPR |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| Parallel ports quantity | 0 |
| Serial ports quantity | 0 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Input current | 0.3 A |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win |
| Mac operating systems supported | Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 55 mm |
| Height | 25 mm |
| Width | 52 mm |
| Weight | 60 g |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 140 x 210 x 53 mm |
| Package width | 151 mm |
| Package depth | 218 mm |
| Package height | 54 mm |
| Package weight | 326 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | LAN (RJ-45) |
| User guide | Yes |
| External power adapter | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | 0 - 40 °C |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 456 mm |
| Master (outer) case length | 328 mm |
| Master (outer) case height | 288 mm |
| Products per master (outer) case | 20 pc(s) |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 100 Mbit/s |
| Chipset | EST2862B |
