Pylon power supply unit
450 W 24-pin ATX ATX Black
Model PylonPart no. PYLON450B-BKCUSEAN 842243020755
19 specifications
- ColourBlack
- Total power450 W
- Motherboard power connector24-pin ATX
- PurposePC
- Width140 mm
Overview
- Colour
- Black
- Total power
- 450 W
- Motherboard power connector
- 24-pin ATX
- Purpose
- PC
- Width
- 140 mm
- Brand
- XPG
- Category
- Power Supply Unit
- Model
- Pylon
- Part numbers
- PYLON450B-BKCUS, PYLON650B-BKCUS, PYLON750B-BKCUS, PYLON750B-BKCGB, PYLON550B-BKCGB, PYLON650B-BKCGB +4 more
- EAN / UPC
- 842243020755
- Also known as
- XPG Pylon power supply unit 450 W 24-pin ATX ATX Black
Specifications
19 specifications in 6 groups
Power
| Specification | Value |
|---|---|
| Total power | 450 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 24-pin ATX |
| EPS power connector (4+4 pin) | Yes |
| ATX Power connector (24-pin) | Yes |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Bronze |
| Mean time between failures (MTBF) | 100000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Fan diameter | 12 cm |
| Fan location | Top |
Certificates
| Specification | Value |
|---|---|
| Certification | CB(62368+60950) / TUV / cTUVus / CE / FCC / BSMI / CCC / RCM / EAC / EAC RoHS / NOM |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 150 mm |
| Height | 86 mm |
