Vultech GS-850R power supply unit
700 W 20+4 pin ATX ATX Black
Model GS-850REAN 8057284623472
46 specifications
- Noise23.4 dB
- ColourBlack
- Total power700 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width150 mm
Overview
- Noise
- 23.4 dB
- Colour
- Black
- Total power
- 700 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 150 mm
- Brand
- Vultech
- Category
- Power Supply Unit
- Model
- GS-850R
- Part number
- GS-850R
- EAN / UPC
- 8057284623472
- Also known as
- Vultech GS-850R power supply unit 700 W 20+4 pin ATX ATX Black
Specifications
46 specifications in 9 groups
Power
| Specification | Value |
|---|---|
| Total power | 700 W |
| Peak power | 850 W |
| AC input voltage | 230 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 5 A |
| Power Factor Correction (PFC) type | Passive |
| Max output current (+3.3V) | 22 A |
| Max output current (+12V1) | 56 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2 A |
| Power protection features | Over current, Over power |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 53 cm |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 2 |
| PCI Express power cable length | 53 cm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 53 cm |
| Floppy drive power connector | 1 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 2.31 |
| Noise level | 23.4 dB |
| Mean time between failures (MTBF) | 50000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | Yes |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, CEE |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 140 mm |
| Height | 85 mm |
Packaging data
| Specification | Value |
|---|---|
| Manual | Yes |
| Package width | 170 mm |
| Package depth | 220 mm |
| Package height | 95 mm |
| Package weight | 2 kg |
Other features
| Specification | Value |
|---|---|
| Noise level (quiet mode, 50%) | 23.4 dB |
| Noise level (full-load mode, 100%) | 23.4 dB |
