Power Supply 2U
600W 80 Plus Bronce
Model UKPSU2U600WEAN 6974560220717
41 specifications
- Weight1.8 kg
- ColourSilver
- Total power600 W
- Motherboard power connector24-pin ATX
- PurposeServer
- Width240 mm
Overview
- Weight
- 1.8 kg
- Colour
- Silver
- Total power
- 600 W
- Motherboard power connector
- 24-pin ATX
- Purpose
- Server
- Width
- 240 mm
- Brand
- UNYKAch
- Category
- Power Supply Unit
- Model
- UKPSU2U600W
- Part number
- UKPSU2U600W
- EAN / UPC
- 6974560220717
- Also known as
- UNYKAch Power Supply 2U 600W 80 Plus Bronce
Specifications
41 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 600 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 5 - 10 A |
| Power Factor Correction (PFC) type | Active |
| Max output current (+3.3V) | 21 A |
| Max output current (+12V1) | 20 A |
| Max output current (+12V2) | 20 A |
| Max output current (+5V) | 22 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 24-pin ATX |
| Motherboard power cable length | 21 cm |
| Number of SATA power connectors | 2 |
| SATA power cable length | 520 mm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Peripheral (Molex) power cable length | 320 mm |
| PCI Express power connectors (8-pin) | 2 |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 3 |
Performance
| Specification | Value |
|---|---|
| Purpose | Server |
| Power supply unit (PSU) form factor | 2U |
| 80 PLUS certification | 80 PLUS Bronze |
| ATX version | 2.3 |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
| Cooling type | Active |
| Fan diameter | 6 cm |
| Number of fans | 1 fan(s) |
| Fan speed | 0 - 5000 RPM |
| Fan location | Front |
| On/off switch | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 240 mm |
| Depth | 100 mm |
| Height | 70 mm |
| Weight | 1.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 240 mm |
| Package depth | 100 mm |
| Package height | 70 mm |
| Package weight | 1.8 kg |
