UKPSU1U40003
Model UKPSU1U40003EAN 6940533543152
38 specifications
- Weight750 g
- ColourSilver
- Total power250 W
- Motherboard power connector20+4 pin ATX
- PurposeServer
- Width85 mm
Overview
- Weight
- 750 g
- Colour
- Silver
- Total power
- 250 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- Server
- Width
- 85 mm
- Brand
- UNYKAch
- Category
- Power Supply Unit
- Model
- UKPSU1U40003
- Part number
- UKPSU1U40003
- EAN / UPC
- 6940533543152
- Also known as
- UNYKAch FLEX ATX
Specifications
38 specifications in 8 groups
Power
| Specification | Value |
|---|---|
| Total power | 250 W |
| AC input voltage | 100 - 250 V |
| AC input frequency | 50 - 60 Hz |
| Power Factor Correction (PFC) type | Active |
| Max output current (+3.3V) | 15 A |
| Max output current (+12V1) | 16 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2 A |
| Efficiency | 87% |
| Power protection features | Over current, Over voltage, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 33 cm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Peripheral (Molex) power cable length | 470,620 mm |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | Server |
| Power supply unit (PSU) form factor | 1U |
| ATX version | 2.3 |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
| Cooling type | Active |
| Fan diameter | 4 cm |
| Number of fans | 1 fan(s) |
| Fan speed | 0 - 1000 RPM |
| Fan location | Rear |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 85 mm |
| Depth | 150 mm |
| Height | 40 mm |
| Weight | 750 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 85 mm |
| Package depth | 150 mm |
| Package height | 40 mm |
| Package weight | 750 g |
Other features
| Specification | Value |
|---|---|
| Mounting type | Rack mounting |
| Screws included | Yes |
| Package volume | 300 cm³ |
