CRPS 2000WR 80 Plus Platinum
Model CRPS 2000WR 80 Plus PlatinumPart no. PSUCRPS2000WREAN 8436617920486
44 specifications
- Weight2.8 kg
- ColourSilver
- Total power2000 W
- Motherboard power connector24-pin ATX
- PurposeServer
- Width84 mm
Overview
- Weight
- 2.8 kg
- Colour
- Silver
- Total power
- 2000 W
- Motherboard power connector
- 24-pin ATX
- Purpose
- Server
- Width
- 84 mm
- Brand
- UNYKAch
- Category
- Power Supply Unit
- Model
- CRPS 2000WR 80 Plus Platinum
- Part number
- PSUCRPS2000WR
- EAN / UPC
- 8436617920486
- Also known as
- UNYKAch Redundant Power Supply CRPS 2000WR 80 Plus Platinum
Specifications
44 specifications in 8 groups
Power
| Specification | Value |
|---|---|
| Total power | 2000 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 10 A |
| Power Factor Correction (PFC) type | Active |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V) | 164 A |
| Max output current (+5V) | 38 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 92% |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 24-pin ATX |
| Motherboard power cable length | 43.5 cm |
| Number of SATA power connectors | 2 |
| SATA power cable length | 100,515 mm |
| Peripheral (Molex) power connectors (4-pin) | 8 |
| Peripheral (Molex) power cable length | 520 mm |
| PCI Express power connectors (8-pin) | 1 |
| PCI Express power cable length | 45.5 cm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 38.5 cm |
| Floppy disk drive cable length | 24 cm |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 3 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | Server |
| Power supply unit (PSU) form factor | CRPS |
| 80 PLUS certification | 80 PLUS Platinum |
| ATX version | 2.3 |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
| Cooling type | Active |
| Number of fans | 2 fan(s) |
| Fan location | Rear |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, cTUVus |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 84 mm |
| Depth | 265 mm |
| Height | 77 mm |
| Weight | 2.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 84 mm |
| Package depth | 265 mm |
| Package height | 77 mm |
| Package weight | 2.9 kg |
Other features
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
