UNYKAch ATX 900W Gaming
Model ATX 900W GamingPart no. 52034EAN 6940533541455
53 specifications
- Noise28 dB
- Weight902 g
- ColourBlack, Transparent
- Total power900 W
- Motherboard power connector20+4 pin ATX
- PurposePC/Server
Overview
- Noise
- 28 dB
- Weight
- 902 g
- Colour
- Black, Transparent
- Total power
- 900 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC/Server
- Brand
- UNYKAch
- Category
- Power Supply Unit
- Model
- ATX 900W Gaming
- Part number
- 52034
- EAN / UPC
- 6940533541455
- Also known as
- UNYKAch ATX 900W Gaming power supply unit 20+4 pin ATX Black, Transparent
Specifications
53 specifications in 9 groups
Power
| Specification | Value |
|---|---|
| Total power | 900 W |
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power Factor Correction (PFC) type | Active |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V1) | 25 A |
| Max output current (+12V2) | 25 A |
| Max output current (+12V3) | 25 A |
| Max output current (+12V4) | 25 A |
| Max output current (+5V) | 24 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over power, Over voltage, Overcharge, Overheating, Overload, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 50 cm |
| Number of SATA power connectors | 8 |
| SATA power cable length | 500,650,800,950 mm |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| Peripheral (Molex) power cable length | 500,650,800 mm |
| PCI Express power connectors (8-pin) | 2 |
| PCI Express power cable length | 50 cm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 50 cm |
| ATX power connector (20+4 pin) | Yes |
| Floppy disk drive cable length | 95 cm |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 1 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC/Server |
| Power supply unit (PSU) form factor | ATX |
| Supported motherboard form factors | ATX |
| ATX version | 2.31 |
| Noise level | 28 dB |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Transparent |
| Cooling type | Active |
| Fan diameter | 14 cm |
| Number of fans | 1 fan(s) |
| LED indicators | Yes |
| On/off switch | Yes |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE / EN60950 / TÜV |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 155 mm |
| Height | 85 mm |
| Weight | 902 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 190 mm |
| Package depth | 205 mm |
| Package height | 170 mm |
| Package weight | 1.08 kg |
| Package type | Box |
Other features
| Specification | Value |
|---|---|
| Screws included | Yes |
| Package volume | 0.0066 cm³ |
