UNYKAch 51976 power supply unit
900 W 20+4 pin ATX ATX Black
Model 51976EAN 6940533540465
26 specifications
- ColourBlack
- Total power900 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width140 mm
Overview
- Colour
- Black
- Total power
- 900 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 140 mm
- Brand
- UNYKAch
- Category
- Power Supply Unit
- Model
- 51976
- Part number
- 51976
- EAN / UPC
- 6940533540465
- Also known as
- UNYKAch 51976 power supply unit 900 W 20+4 pin ATX ATX Black
Specifications
26 specifications in 6 groups
Power
| Specification | Value |
|---|---|
| Total power | 900 W |
| AC input voltage | 100 - 240 V |
| Maximum input current (@110V) | +12V |
| Power Factor Correction (PFC) type | Active |
| Efficiency | 80% |
| Power protection features | Over voltage, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| Floppy disk drive connector | Yes |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Bronze |
| ATX version | 2.3 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, TUV, ErP617, EN60950 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 140 mm |
| Depth | 150 mm |
| Height | 85 mm |
