TP-Link 100-240V Redundant Power Supply Module
Model TL-MCRP100EAN 8459730020222
22 specifications
- ColourBlack
- Total power75 W
- Operating temperature (T-T)0 - 60 °C
- Width210 mm
Overview
- Colour
- Black
- Total power
- 75 W
- Operating temperature (T-T)
- 0 - 60 °C
- Width
- 210 mm
- Brand
- TP-Link
- Category
- Power Supply Unit
- Model
- TL-MCRP100
- Part numbers
- TL-MCRP100, TL-MCRP100 V2
- EAN / UPC
- 8459730020222, 1210002612159, 2002396710004, 5415247006282 +3 more
- Also known as
- TP-Link 100-240V Redundant Power Supply Module
Specifications
22 specifications in 6 groups
Power
| Specification | Value |
|---|---|
| Total power | 75 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.8 A |
| Max output current (+12V) | 6.25 A |
| Power protection features | Over power, Overload, Short circuit |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Illumination | Yes |
| LED indicators | Power |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -35 - 85 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 10 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 130 mm |
| Height | 70 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 250 mm |
| Package depth | 400 mm |
| Package height | 80 mm |
| Package weight | 1.5 kg |
Other features
| Specification | Value |
|---|---|
| Illumination colour | Green |
| Power management | Yes |
