TooQ TQXGE-525SAP power supply unit
525 W 20+4 pin ATX ATX Black
Model TQXGE-525SAPEAN 8433281006355
37 specifications
- Noise17 dB
- ColourBlack
- Total power525 W
- Motherboard power connector20+4 pin ATX
- Power supply unit (PSU) form factorATX
- Operating temperature (T-T)0 - 40 °C
Overview
- Noise
- 17 dB
- Colour
- Black
- Total power
- 525 W
- Motherboard power connector
- 20+4 pin ATX
- Power supply unit (PSU) form factor
- ATX
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- TooQ
- Category
- Power Supply Unit
- Model
- TQXGE-525SAP
- Part number
- TQXGE-525SAP
- EAN / UPC
- 8433281006355
- Also known as
- TooQ TQXGE-525SAP power supply unit 525 W 20+4 pin ATX ATX Black
Specifications
37 specifications in 10 groups
Power
| Specification | Value |
|---|---|
| Total power | 525 W |
| AC input voltage | 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 10 A |
| Power Factor Correction (PFC) type | Active |
| Efficiency | 80% |
| Hold time | 17 ms |
| Power protection features | Over current, Over voltage, Overload, Short circuit, Under voltage, Overheating |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 5 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| Floppy drive power connector | 1 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Power supply unit (PSU) form factor | ATX |
| ATX version | 1.3 |
| EPS version | 2.92 |
| Noise level | 17 dB |
| Mean time between failures (MTBF) | 100000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Fan diameter | 14 cm |
| Number of fans | 1 fan(s) |
| Illumination | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE / UL / FCC / BSMI / GOST / CCC / KCC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 160 mm |
| Height | 86 mm |
Packaging data
| Specification | Value |
|---|---|
| Manual | Yes |
| Package width | 105 mm |
| Package depth | 280 mm |
| Package height | 235 mm |
| Package weight | 2.38 kg |
Other features
| Specification | Value |
|---|---|
| Illumination colour | Blue |
