48V DC Industrial Power Supply
480W, DIN-Rail, PoE Ready
Model POW-4861EAN 4015867206515
22 specifications
- Weight1.5 kg
- ColourBlue, Silver
- Total power480 W
- Peripheral (Molex) power connectors (4-pin)0
- Mean time between failures (MTBF)146800 h
- Operating temperature (T-T)-20 - 70 °C
Overview
- Weight
- 1.5 kg
- Colour
- Blue, Silver
- Total power
- 480 W
- Peripheral (Molex) power connectors (4-pin)
- 0
- Mean time between failures (MTBF)
- 146800 h
- Operating temperature (T-T)
- -20 - 70 °C
- Brand
- LevelOne
- Category
- Power Supply Unit
- Model
- POW-4861
- Part number
- POW-4861
- EAN / UPC
- 4015867206515, 5715063408810
- Also known as
- LevelOne 48V DC Industrial Power Supply, 480W, DIN-Rail, PoE Ready
Specifications
22 specifications in 10 groups
Power
| Specification | Value |
|---|---|
| Total power | 480 W |
| AC input voltage | 90 - 264 V |
| Power protection features | Over voltage, Overload, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Peripheral (Molex) power connectors (4-pin) | 0 |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 146800 h |
Design
| Specification | Value |
|---|---|
| Product colour | Blue, Silver |
| LED indicators | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 95% |
Safety regulation & standards
| Specification | Value |
|---|---|
| Safety | UL508, TUV EN60950-1,approved;(meet EN60204-1) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 125.2 mm |
| Depth | 128.5 mm |
| Height | 85.5 mm |
| Weight | 1.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 125.2 mm |
| Package depth | 128.5 mm |
| Package height | 85.5 mm |
| Package weight | 1.5 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Country of origin | China |
Other features
| Specification | Value |
|---|---|
| Maximum current | 10 A |
| Technical features | 48V DC Out |
