LevelOne 48V DC Industrial Power Supply
48V DC, 40W, DIN-Rail
Model POW-4811EAN 4015867207789
23 specifications
- Weight300 g
- ColourBlue, White
- Total power39.8 W
- Peripheral (Molex) power connectors (4-pin)0
- Mean time between failures (MTBF)301700 h
- Operating temperature (T-T)-20 - 70 °C
Overview
- Weight
- 300 g
- Colour
- Blue, White
- Total power
- 39.8 W
- Peripheral (Molex) power connectors (4-pin)
- 0
- Mean time between failures (MTBF)
- 301700 h
- Operating temperature (T-T)
- -20 - 70 °C
- Brand
- LevelOne
- Category
- Power Supply Unit
- Model
- POW-4811
- Part number
- POW-4811
- EAN / UPC
- 4015867207789
- Also known as
- LevelOne 48V DC Industrial Power Supply, 48V DC, 40W, DIN-Rail
Specifications
23 specifications in 10 groups
Power
| Specification | Value |
|---|---|
| Total power | 39.8 W |
| Peak power | 40 W |
| AC input voltage | 85 - 264 V |
| Power protection features | Over voltage, Overload, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Peripheral (Molex) power connectors (4-pin) | 0 |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 301700 h |
Design
| Specification | Value |
|---|---|
| Product colour | Blue, White |
| LED indicators | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 90% |
Safety regulation & standards
| Specification | Value |
|---|---|
| Safety | UL508, TUV EN60950-1 Approved,EN55011, EN55022 (CISPR22), EN61204-3 Class B,EN61000-4-2, 3, 4, 5, 6, 8, 11, ENV50204, EN55024, EN61000-6-2, EN61204-3 heavy |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 90 mm |
| Depth | 40 mm |
| Height | 100 mm |
| Weight | 300 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 90 mm |
| Package depth | 100 mm |
| Package height | 40 mm |
| Package weight | 350 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Country of origin | China |
Other features
| Specification | Value |
|---|---|
| Maximum current | 0.83 A |
| Technical features | 48V DC Out |
