GIGABYTE Pluse power supply unit
450 W 24-pin ATX ATX Black
Model PlusePart no. 2AEFS-45AC9-A11SEAN 4719331133719
30 specifications
- ColourBlack
- Total power450 W
- Motherboard power connector24-pin ATX
- PurposePC
- SafetyCB, CE, CCC, EAC, TUV
- Width150 mm
Overview
- Colour
- Black
- Total power
- 450 W
- Motherboard power connector
- 24-pin ATX
- Purpose
- PC
- Safety
- CB, CE, CCC, EAC, TUV
- Width
- 150 mm
- Brand
- GIGABYTE
- Category
- Power Supply Unit
- Model
- Pluse
- Part numbers
- 2AEFS-45AC9-A11S, 2AEFS-55AC9-A11S
- EAN / UPC
- 4719331133719, 4719331133726
- Also known as
- GIGABYTE Pluse power supply unit 450 W 24-pin ATX ATX Black
Specifications
30 specifications in 6 groups
Power
| Specification | Value |
|---|---|
| Total power | 450 W |
| AC input voltage | 100 - 240 V |
| Input current | 5 - 10 A |
| Maximum input current (@110V) | +12V,+3.3V,+5V,+5Vsb,-12V |
| Combined power (+3.3V) | 80 W |
| Combined power (+12V) | 444 W |
| Combined power (+5V) | 80 W |
| Max output current (+3.3V) | 15 A |
| Max output current (+12V) | 37 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 2.5 A |
| Efficiency | 82% |
| Power protection features | Over power, Over voltage, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 3 |
| CPU power connector (4+4 pin) | Yes |
| Floppy drive power connector | 1 |
| Cabling type | Semi-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Bronze |
| ATX version | 2.31 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Safety regulation & standards
| Specification | Value |
|---|---|
| Safety | CB, CE, CCC, EAC, TUV |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
