SDA2-650 power supply unit
650 W SFX Black
Model SDA2-650
28 specifications
- ColourBlack
- Total power650 W
- Cabling typeFully-Modular
- PurposePC
- Width100 mm
Overview
- Colour
- Black
- Total power
- 650 W
- Cabling type
- Fully-Modular
- Purpose
- PC
- Width
- 100 mm
- Brand
- FSP
- Category
- Power Supply Unit
- Model
- SDA2-650
- Part number
- SDA2-650
- Also known as
- FSP SDA2-650 power supply unit 650 W SFX Black
Specifications
28 specifications in 5 groups
Power
| Specification | Value |
|---|---|
| Total power | 650 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 5 - 10 A |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 648 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 54 A |
| Max output current (+5V) | 22 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Efficiency | 90% |
Ports & interfaces
| Specification | Value |
|---|---|
| Cabling type | Fully-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | SFX |
| 80 PLUS certification | 80 PLUS Gold |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Mean time between failures (MTBF) | 200000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 9.2 cm |
| Number of fans | 1 fan(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Depth | 125 mm |
| Height | 63.5 mm |
