HPT2-650M power supply unit
650 W ATX
Model HPT2-650M
17 specifications
- Total power650 W
- Cabling typeFully-Modular
- PurposePC
- Cooling typeActive
- Width170 mm
Overview
- Total power
- 650 W
- Cabling type
- Fully-Modular
- Purpose
- PC
- Cooling type
- Active
- Width
- 170 mm
- Brand
- FSP
- Category
- Power Supply Unit
- Model
- HPT2-650M
- Part number
- HPT2-650M
- Also known as
- FSP HPT2-650M power supply unit 650 W ATX
Specifications
17 specifications in 5 groups
Power
| Specification | Value |
|---|---|
| Total power | 650 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 10 - 5 A |
| Power Factor Correction (PFC) type | Active |
| Efficiency | 92% |
| Power protection features | Over power, Over voltage, Under voltage, Over current, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Cabling type | Fully-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Platinum |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Number of fans | 1 fan(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 170 mm |
| Depth | 150 mm |
| Height | 86 mm |
