Twins PRO 930W Power Module for PS2 ATX Redundant Twins Pro 900
Model FSP930-20REBPart no. 9PA9300201EAN 4713224524837
26 specifications
- ColourBlack
- Total power930 W
- Motherboard power connector20+4 pin ATX
- PurposePC/Server
- Width86 mm
Overview
- Colour
- Black
- Total power
- 930 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC/Server
- Width
- 86 mm
- Brand
- FSP
- Category
- Power Supply Unit
- Model
- FSP930-20REB
- Part number
- 9PA9300201
- EAN / UPC
- 4713224524837
- Also known as
- FSP Twins PRO 930W Power Module for PS2 ATX Redundant Twins Pro 900
Specifications
26 specifications in 6 groups
Power
| Specification | Value |
|---|---|
| Total power | 930 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 10-6 A |
| Max output current (+12V) | 77.5 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| PCI Express power connectors (6+2 pin) | 4 |
| CPU power connector (4+4 pin) | Yes |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 1 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC/Server |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Gold |
| Bearing technology | Ball bearing |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 4 cm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | CPU, PCIe, Peripheral (Molex), SATA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 86 mm |
| Depth | 150 mm |
| Height | 190 mm |
