FSP460-60PFB power supply unit
460 W ATX Stainless steel
Model FSP460-60PFB
35 specifications
- ColourStainless steel
- Total power460 W
- Connector(s)IEC C14
- PurposePC
- Operating temperature (T-T)0 - 50 °C
- SafetyCB,CE, FCC
Overview
- Colour
- Stainless steel
- Total power
- 460 W
- Connector(s)
- IEC C14
- Purpose
- PC
- Operating temperature (T-T)
- 0 - 50 °C
- Safety
- CB,CE, FCC
- Brand
- FSP
- Category
- Power Supply Unit
- Model
- FSP460-60PFB
- Part number
- FSP460-60PFB
- Also known as
- FSP FSP460-60PFB power supply unit 460 W ATX Stainless steel
Specifications
35 specifications in 8 groups
Power
| Specification | Value |
|---|---|
| Total power | 460 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 6 A |
| Maximum input current (@110V) | +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V |
| Power factor | 0.99 |
| Power Factor Correction (PFC) type | Active |
| Max output current (+3.3V) | 15.7 A |
| Max output current (+12V) | 26.5 A |
| Max output current (+5V) | 14.4 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 2.5 A |
| Efficiency | 84.61% |
| Power protection features | Over voltage, Overload, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| Connector(s) | IEC C14 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS |
| Mean time between failures (MTBF) | 100000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Stainless steel |
| Fan diameter | 8 cm |
| Number of fans | 1 fan(s) |
| Fan location | Side |
| LED indicators | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Safety regulation & standards
| Specification | Value |
|---|---|
| Safety | CB,CE, FCC |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 140 x 150 x 86 mm |
| Parallel processing technology support | Not supported |
| Power over Ethernet (PoE) | No |
| Redundant power supply (RPS) support | No |
| Power rocker switch | No |
