FSP350-60APN 85+
FSP

FSP350-60APN 85+

Model FSP350-60APN 85+Part no. 9PA350AN05EAN 4016138654462

40 specifications
  • Noise29.1 dB
  • ColourGrey
  • Total power350 W
  • Motherboard power connector20+4 pin ATX
  • PurposePC
  • Width150 mm
See all specifications

Overview

Noise
29.1 dB
Colour
Grey
Total power
350 W
Motherboard power connector
20+4 pin ATX
Purpose
PC
Width
150 mm
Brand
FSP
Model
FSP350-60APN 85+
Part numbers
9PA350AN05, 9PA350A901
EAN / UPC
4016138654462, 4053846399766, 4711140488585
Also known as
FSP FSP350-60APN 85+ power supply unit 350 W 20+4 pin ATX ATX Grey

Specifications

40 specifications in 7 groups

Power

Total power350 W
Peak power400 W
AC input voltage180 - 264 V
AC input frequency47 - 63 Hz
Input current2.5 A
Maximum input current (@110V)+12V1,+12V2,+3.3V,+5V,-12V,-5Vsb
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)103 W
Combined power (+5V)103 W
Combined power (-12V)16.1 W
Combined power (+5Vsb)16.1 W
Max output current (+3.3V)21 A
Max output current (+12V1)16 A
Max output current (+12V2)16 A
Max output current (+5V)15 A
Max output current (-12V)0.3 A
Max output current (+5Vsb)2.5 A
Efficiency85.74%
Power protection featuresOver current, Over power, Over voltage, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector20+4 pin ATX
Number of SATA power connectors3
Peripheral (Molex) power connectors (4-pin)2
CPU P4 connector (4-pin)1
ATX power connector (20+4 pin)Yes
Floppy drive power connector1
Cabling typeNon-Modular

Performance

PurposePC
Power supply unit (PSU) form factorATX
ATX version2.4
Noise level29.1 dB

Design

Product colourGrey
Cooling typeActive
Number of fans1 fan(s)
Fan locationSide
On/off switchYes

Certificates

Compliance certificatesRoHS

Weight & dimensions

Width150 mm
Depth140 mm
Height86 mm

Technical details

Sustainability certificatesENERGY STAR
