FSP250-60EGA 90+
Model FSP250-60EGA 90+Part no. 9PA250DA02EAN 4711140488516
36 specifications
- ColourGrey
- Total power250 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width150 mm
- Sustainability certificatesENERGY STAR
Overview
- Colour
- Grey
- Total power
- 250 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 150 mm
- Sustainability certificates
- ENERGY STAR
- Brand
- FSP
- Category
- Power Supply Unit
- Model
- FSP250-60EGA 90+
- Part number
- 9PA250DA02
- EAN / UPC
- 4711140488516
- Also known as
- FSP FSP250-60EGA 90+ power supply unit 250 W 20+4 pin ATX ATX Grey
Specifications
36 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 250 W |
| AC input voltage | 90 - 264 V |
| AC input frequency | 47 - 63 Hz |
| Input current | 4 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 97 W |
| Combined power (+12V) | 240 W |
| Combined power (+5V) | 97 W |
| Combined power (-12V) | 18.6 W |
| Combined power (+5Vsb) | 18.6 W |
| Max output current (+3.3V) | 14 A |
| Max output current (+12V1) | 17 A |
| Max output current (+12V2) | 17 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 4 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Gold |
| Bearing technology | Ball bearing |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
| Fan diameter | 8 cm |
| Number of fans | 1 fan(s) |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | ErP 2013 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
