FSP Aurum Pro 1000

FSP Aurum Pro 1000

Model Aurum Pro 1000Part no. PPA10A1411EAN 4711140488066

47 specifications
  • Noise135 dB
  • Weight3.53 kg
  • ColourBlack
  • Total power1200 W
  • Motherboard power connector24-pin ATX
  • PurposePC
See all specifications

Overview

Noise
135 dB
Weight
3.53 kg
Colour
Black
Total power
1200 W
Motherboard power connector
24-pin ATX
Purpose
PC
Brand
FSP
Model
Aurum Pro 1000
Part numbers
PPA10A1411, PPA12A0404, PPA10A1401
EAN / UPC
4711140488066, 845685001993, 4711140485867, 4711140488073 +1 more
Also known as
FSP Aurum Pro 1000 power supply unit 1200 W 24-pin ATX ATX Black

Specifications

47 specifications in 8 groups

Power

Total power1200 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Maximum input current (@110V)+12V,+3.3V,+5V,+5Vsb,-12V
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)160 W
Combined power (+12V)1200 W
Combined power (+5V)160 W
Combined power (-12V)24.6 W
Combined power (+5Vsb)24.6 W
Max output current (+3.3V)25 A
Max output current (+12V)100 A
Max output current (+5V)25 A
Max output current (-12V)0.8 A
Max output current (+5Vsb)3 A
Efficiency90%
Power protection featuresOver current, Over voltage, Short circuit

Ports & interfaces

Motherboard power connector24-pin ATX
Number of SATA power connectors10
Peripheral (Molex) power connectors (4-pin)6
PCI Express power connectors (6+2 pin)8
CPU power connector (4+4 pin)Yes
ATX Power connector (24-pin)Yes
Floppy drive power connector1
CPU power connectors (8-pin)1
Cabling typeSemi-Modular

Performance

PurposePC
Power supply unit (PSU) form factorATX
80 PLUS certification80 PLUS Gold
ATX version2.31
EPS version2.92
Noise level135 dB

Design

Product colourBlack
Cooling typeActive
Fan diameter13.5 cm
Number of fans1 fan(s)
Fan locationTop
On/off switchYes

Safety regulation & standards

SafetycUL, FCC, CE, TUV, GOST, BSMI, CCC

Weight & dimensions

Width150 mm
Depth180 mm
Height86 mm
Weight3.53 kg

Packaging data

Package width267 mm
Package depth355 mm
Package height96 mm

Other features

Omnigrid (2-pin) power connectors2
