FSP Aurum CM 550

FSP Aurum CM 550

Model Aurum CM 550Part no. PPA5501601EAN 4711140481722

49 specifications
  • Noise21 dB
  • Weight2.53 kg
  • ColourBlack
  • Total power550 W
  • Motherboard power connector20+4 pin ATX
  • PurposePC
See all specifications

Overview

Noise
21 dB
Weight
2.53 kg
Colour
Black
Total power
550 W
Motherboard power connector
20+4 pin ATX
Purpose
PC
Brand
FSP
Model
Aurum CM 550
Part numbers
PPA5501601, PPA5501610
EAN / UPC
4711140481722, 4711140485812
Also known as
FSP Aurum CM 550 power supply unit 550 W 20+4 pin ATX ATX Black

Specifications

49 specifications in 7 groups

Power

Total power550 W
AC input voltage90 - 264 V
AC input frequency47 - 63 Hz
Input current4 - 8 A
Maximum input current (@110V)+12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)140 W
Combined power (+5V)140 W
Combined power (-12V)23.5 W
Combined power (+5Vsb)23.5 W
Max output current (+3.3V)24 A
Max output current (+12V1)18 A
Max output current (+12V2)18 A
Max output current (+12V3)18 A
Max output current (+12V4)18 A
Max output current (+5V)24 A
Max output current (-12V)0.5 A
Max output current (+5Vsb)3.5 A
Efficiency90%
Power protection featuresOver current, Over voltage, Short circuit

Ports & interfaces

Motherboard power connector20+4 pin ATX
Number of SATA power connectors7
Peripheral (Molex) power connectors (4-pin)4
EPS power connector (8-pin)Yes
PCI Express power connectors (6+2 pin)4
CPU power connector (4+4 pin)Yes
ATX power connector (20+4 pin)Yes
Floppy drive power connector1
Cabling typeSemi-Modular

Performance

PurposePC
Power supply unit (PSU) form factorATX
80 PLUS certification80 PLUS Gold
ATX version2.3
EPS version2.92
Noise level21 dB

Design

Product colourBlack
Cooling typeActive
Fan diameter12 cm
Number of fans1 fan(s)
Fan locationTop
On/off switchYes

Safety regulation & standards

SafetycUL, FCC, CE, TUV, GOST, BSMI, CCC

Weight & dimensions

Width160 mm
Depth150 mm
Height86 mm
Weight2.53 kg

Packaging data

Package width245 mm
Package depth327 mm
Package height96 mm
