FSP 9PA300DK08 power supply unit
300 W 24-pin ATX TFX Grey
Model 9PA300DK08
35 specifications
- ColourGrey
- Total power300 W
- Motherboard power connector24-pin ATX
- PurposePC
- Width85 mm
- Sustainability certificatesENERGY STAR
Overview
- Colour
- Grey
- Total power
- 300 W
- Motherboard power connector
- 24-pin ATX
- Purpose
- PC
- Width
- 85 mm
- Sustainability certificates
- ENERGY STAR
- Brand
- FSP
- Category
- Power Supply Unit
- Model
- 9PA300DK08
- Part number
- 9PA300DK08
- Also known as
- FSP 9PA300DK08 power supply unit 300 W 24-pin ATX TFX Grey
Specifications
35 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 300 W |
| AC input voltage | 90 - 264 V |
| AC input frequency | 47 - 53 Hz |
| Input current | 2 - 4 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 103 W |
| Combined power (+12V) | 288 W |
| Combined power (+5V) | 103 W |
| Combined power (-12V) | 16 W |
| Combined power (+5Vsb) | 16 W |
| Max output current (+3.3V) | 18 A |
| Max output current (+12V1) | 13 A |
| Max output current (+12V2) | 13 A |
| Max output current (+5V) | 18 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90.58% |
| Power protection features | Over voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 3 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| CPU P4 connector (4-pin) | 1 |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 1 |
| Cabling type | Non-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | TFX |
| 80 PLUS certification | 80 PLUS Gold |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
| Number of fans | 1 fan(s) |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 85 mm |
| Depth | 175 mm |
| Height | 65 mm |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
