ELECTRA-SDR-480-48 power supply unit
480 W Blue
Model ELECTRA-SDR-480-48
21 specifications
- Weight1.4 kg
- ColourBlue
- Total power480 W
- Operating temperature (T-T)-20 - 70 °C
- SafetyUl508, TUV EN60950-1
- Width85.5 mm
Overview
- Weight
- 1.4 kg
- Colour
- Blue
- Total power
- 480 W
- Operating temperature (T-T)
- -20 - 70 °C
- Safety
- Ul508, TUV EN60950-1
- Width
- 85.5 mm
- Brand
- Ernitec
- Category
- Power Supply Unit
- Model
- ELECTRA-SDR-480-48
- Part number
- ELECTRA-SDR-480-48
- Also known as
- Ernitec ELECTRA-SDR-480-48 power supply unit 480 W Blue
Specifications
21 specifications in 7 groups
Power
| Specification | Value |
|---|---|
| Total power | 480 W |
| Input current | 4.8 A |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over voltage |
Design
| Specification | Value |
|---|---|
| Product colour | Blue |
| Cooling type | Passive |
| On/off switch | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
Safety regulation & standards
| Specification | Value |
|---|---|
| Safety | Ul508, TUV EN60950-1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 85.5 mm |
| Depth | 128.5 mm |
| Height | 125.2 mm |
| Weight | 1.4 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 260 mm |
| Package depth | 355 mm |
| Package height | 315 mm |
| Package weight | 1.58 kg |
Other features
| Specification | Value |
|---|---|
| Output power description | 480W |
